Jeep Wrangler JL with DANA 35 ADVANTEK / 200mm REAR
2018 and Newer Jeep Wrangler JL - Sport/Sahara w/3.6L Engine and Open Rear Differential
Diff Specifications - M200 Rear.... USA Metric
- Ring Gear Bolt (DRY / NO OIL)..............135 – 155 ft-lbs / 180 – 210 Nm
- Bearing Cap Bolt...................................44.25 – 51.5 ft-lbs / 60 – 70 Nm
- Ring Gear Backlash ................................0.003 – 0.006 / .08 – .15 mm
- Diff Cover Bolt...........................................25 – 30 ft-lbs / 35 – 40 Nm
- Diff Cover Plug..........................................15 – 25 ft-lbs / 20 – 34 Nm
- Axle Shaft Retainer Plate Nut................55.5 – 62.5 ft-lbs / 75 – 85 Nm
- EDL Connector Screw .............................. 7 – 8.5 ft-lbs / 9 – 12 Nm
- Carrier Drain Plug .....................................15 – 25 ft-lbs / 20 – 34 Nm
- Lubricant Capacity ...................................... 2.43 pts. / 1.15 L
- Lubricant Type ........................... SAE 75W-140 Gear Lubricant
Drive Pinion and Total Torque to Rotate
- Drive Pinion Torque to Rotate (PTR) .. 7.43 – 16.99 in-lbs / 0.84 – 1.92 Nm
Ring & Pinions
- 3.45 - 10060460
- 4.10 - 10095819
- 4.56 - 10067221
- 4.88 - 10067231
- 5.13 - 10067244
Differential Bearing Kits
- Standard Differential Bearing Kits - 10040451
- Master Differential Bearing Kit - 10040452
Differential Carrier Case Kits
- Standard OPEN Differential loaded case - 10063459
- All cases come loaded with gearing unless otherwise noted.
Differential Spider Gear Kits
- Standard OPEN Diff. Inner Spider Gear Kit - 10063481
Differential Cover Kits
- Sampled Steel Cover Kit (w/ HDW) - 10005626
- Nodular Iron - Performance (w/ HDW & RTV Sealant) - 10044349
- Dana Blue Performance Cover (w/ HDW & RTV Sealant) - 10053467
Chromoly Axle Shafts
- 2018 & Newer Jeep Wrangler JL Left Rear - 10043051
- 2018 & Newer Jeep Wrangler JL Right Rear - 10043051
- Note: See Axle Shaft Detailed Application Section for year/make/model search
Misc. Components
- Friction Modifier/POSI Additive - 43161
- RTV Sealant (2.8 oz.) - 70-31414-10
- EDL Connector Screw - 10039789
- Inner Pinion Bearing Kit - 10063491
- Outer Pinion Bearing Kit - 2014967-2
- Pinion Shim Kit - 10040465
- Differential Bearing Kit - 10063464
- Differential Shim Kit - 10040466
- Diff Cover Bolt - 10050881
- Pinion Oil Seal - 2010953-2
- Axle Shaft Wheel Bearing - 565904
- Axle Shaft Wheel Bearing Retainer -
- Axle Shaft Retainer Plate Nut - 2004922
- Wheel Seal - 2021013-1
- Axle Shaft Wheel Stud - 10047625
- Pinion Nut - 2009624
- Collapsible Spacer - 10008365
- Companion Flange Assembly - 10020112
- Ring Gear Bolts - 10008806
- Bearing Cap Bolt - 2002348-4
- Drain Plug - 2019554-1
- Transfer Case End Yoke (1310 Series) - 10016266 see note below
- Transfer Case End Yoke (1350 Series) - 10016268 see note below
- NOTE: Replaces OE Style Companion Flange at Transfer Case
DANA 35 ADVANTEK REAR Jeep JL
|
