Denny's Driveshaft builds custom steel and aluminum driveshafts for your high performance car, street rod, race car, van, pick up or 4x4 truck

Dana Spicer 211355X fits 1967 to 1977 Chevy and GMC 4X4 CV Centering Yoke for 1310 Series Front CV Driveshaft GREASEABLE
Part Number:
211355X


UPC:
023913228972
Your Cost $56.95
STATUS:  IN STOCK

DANA SPICER 211355X

1967 to 1977 Chevy & GMC CV Front Driveshaft Spicer Style Centering Yoke 1310 Series Includes spring

  • Use on any 1310 series CV Driveshaft to repair or rebuild Double Cardan Joint
  • 1310 Series... Measures 3 1/4 inches between Tabs in centering Yoke
  • GREASEABLE center ball socket
  • New spring Included

DIMENSIONS
  • Fits 1310 U-Joint
    • (3.219 inches) 3-7/32 inches between locating tabs on centering yoke
    • (1.062 inches) 1-1/16 inch dimension of saddle to hold U-Joint Bearing cap
  • Bolt Holes are 5/16 - 24 fine thread
    • Bolt hole spacing 1.500 inches across u-joint cap
    • Bolt hole spacing 2.343 inches side to side
  • Fits .500 inch stud diameter
INCLUDES
  • New spring Included

Spicer
Dana Spicer 211355X fits 1967 to 1977 Chevy and GMC 4X4 CV Centering Yoke for 1310 Series Front CV Driveshaft GREASEABLE
Dana Spicer 211355X fits 1967 to 1977 Chevy and GMC 4X4 CV Centering Yoke for 1310 Series Front CV Driveshaft GREASEABLE
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $56.95

DANA SPICER 211355X

1967 to 1977 Chevy & GMC CV Front Driveshaft Spicer Style Centering Yoke 1310 Series Includes spring

  • Use on any 1310 series CV Driveshaft to repair or rebuild Double Cardan Joint
  • 1310 Series... Measures 3 1/4 inches between Tabs in centering Yoke
  • GREASEABLE center ball socket
  • New spring Included

DIMENSIONS
  • Fits 1310 U-Joint
    • (3.219 inches) 3-7/32 inches between locating tabs on centering yoke
    • (1.062 inches) 1-1/16 inch dimension of saddle to hold U-Joint Bearing cap
  • Bolt Holes are 5/16 - 24 fine thread
    • Bolt hole spacing 1.500 inches across u-joint cap
    • Bolt hole spacing 2.343 inches side to side
  • Fits .500 inch stud diameter
INCLUDES
  • New spring Included
Dana Spicer 211355X fits 1967 to 1977 Chevy and GMC 4X4 CV Centering Yoke for 1310 Series Front CV Driveshaft GREASEABLE

Dana Spicer 211355X fits 1967 to 1977 Chevy and GMC 4X4 CV Centering Yoke for 1310 Series Front CV Driveshaft GREASEABLE
