JEEP Dana 30 Front

Diagram #	Part #	Description	Diagram #	Part #	Description
1	*****	Housing - For reference only	32-38	Multiple	Ball joints
2	Multiple	Gear Set	39	36326-1	Spindle Bolt
3	Multiple	Slinger	40-41		Knuckle RT / LF
4	Multiple	Inner Pinion Bearing	42, 43, 44		Tie Rod
5	Multiple	Shims	45	Multiple	Axle Shaft Parts
6	32349	Baffle	46	Multiple	Slinger Inner Shaft
7	Multiple	Shims or Crush Collar	47	Multiple	Slinger Outer Shaft
8	Multiple	Pinion Bearing	48, 49, 50, 51	Multiple	Spindle Bearing and Seals
9	Multiple	Slinger	52		Spindle
10	Multiple	Pinion Seal	53	CLN375-24	Nut for Spindle Bolt #39
11	2-4-8091X	Pinion Yoke	54	Multiple	Wheel Hub Seal
12		Slinger - comes with yoke	55	Multiple	Inner wheel bearing
13	30186	Washer	56		Wheel Hub
14	30185	Pinion Nut	57	Multiple	Outer Wheel Bearing
15	Multiple	Diff Cover	58, 59, 60		Nut and lock washer
16	38615	Gasket or RTV	61		Gasket
17	36472	Fill Plug	62		Flange
18	34279	Cover Bolt	63		Snap ring
19		Diff Bearing Cap	64		Cap
20		Bolt for bearing cap	65, 66		Bolt and washer
21	706016X	Diff side Bearings	67		Unit Hub Bearing Assembly
22	Multiple	Diff side Bearing Shims	68	40596	Flat washer
23	Multiple	Diff Case / Carrier	69	40597	Hex Nut
24	41221	Ring Gear Bolt	70	40598	Nut retainer
25	Multiple	Small spider gear - See Kit	71		Cotter pin
26	Multiple	Large side spider gear - See Kit	72	Multiple	Dust shield or ABS tone ring
27	Multiple	Thrustwasher - See Kit	73		Spring washer
28	Multiple	Thrustwasher - See Kit
29	41648	Cross shaft
30	13449	Roll pin
31	46470	Tube Seal

DANA 30 - FRONT

DUST SHIELD / ABS TONE RING

Fits Outer Stub Axle

	DANA SPICER 44646 ABS Tone Ring for Jeep 43205 outer axle CLICK HERE for More Details Part Number: 44646	$15.74	IN STOCK

	Dana Spicer 36364 Seal Retainer for Outer Axle Shaft YA D36617 CLICK HERE for More Details Part Number: 36364	$2.95	IN STOCK

	DANA SPICER 40589 Outer Axle Dust Shield 2.790 ID fits 40611 outer axle shaft that requires 5-260X u-joint CLICK HERE for More Details Part Number: 40589	~~$8.89~~ $7.98

	DANA SPICER 46988 Dust Shield 2.735 ID for outer stub axle shaft 43205 fits Dana 30 Disconnect front 1984 to 2006 Jeep YJ, TJ, XJ, ZJ without ABS CLICK HERE for More Details Part Number: 46988	$3.85	IN STOCK

Fits Inner Axle Shaft

	Dana Spicer 701113X Plastic dust shield for inner axle shaft CLICK HERE for More Details Part Number: 701113X	$37.77	IN STOCK

	Dana Spicer 35168 Dust Shield for Inner Axle Shaft to keep dirt out of axle tube fits 1972 to 1986 Jeep CJ with DANA 30 front axle CLICK HERE for More Details Part Number: 35168	~~$4.30~~ $4.04

	Dana Spicer 46849 Dust Shield for Right and Left side Inner Axle Shaft CLICK HERE for More Details Part Number: 46849	$4.06	IN STOCK

AXLE - OUTER NUT and WASHER

	Dana Spicer 2008564 Outer Axle Nut Jeep JK Wrangler 2007 - 2018 CLICK HERE for More Details Part Number: 2008564	$13.95	IN STOCK

	DANA SPICER 40596 JEEP Outer Axle Nut Washer - up to 2006 CLICK HERE for More Details Part Number: 40596	$1.22	IN STOCK

	DANA SPICER 40597 JEEP Outer Axle Nut - up to 2006 CLICK HERE for More Details Part Number: 40597	$18.52	IN STOCK

	DANA SPICER 40598 JEEP Outer Axle Nut Retainer - up to 2006 CLICK HERE for More Details Part Number: 40598	$11.95	IN STOCK

AXLE U-JOINTS

	DANA SPICER 5-260X Front Axle Universal Joint for Dana 30 front CLICK HERE for More Details Part Number: 5-260X	$29.95	SOLD OUT

	Dana Spicer 5-760X JEEP Front 4x4 Axle Universal Joint Non Greaseable CLICK HERE for More Details Part Number: 5-760X	$28.56	IN STOCK

AXLE - OUTER

Fits 5-260X U-Joint

	Yukon YA D36617 outer stub axle 8.72 inches for 1977 to 1983 Jeep CJ5, 1977 to 1986 Jeep CJ7 and 1974 to 1977 IH Scout all with Dana 30 Front - Fits small 5-260X axle u-joint CLICK HERE for More Details Part Number: YA D36617	$196.24	FACTORY DIRECT

	Dana Spicer 10025618 CHROMOLY OUTER AXLE 6.11 inches fits 5-260X u-joint with 1.062 cap diameter DANA 30 Front Axle CLICK HERE for More Details Part Number: 10025618	~~$169.15~~ $149.95	IN STOCK FREE SHIPPING

Fits 5-760X U-Joint

	Dana Spicer 10007747 CHROMOLY Outer Axle Stub Shaft replaces 43205 CLICK HERE for More Details Part Number: 10007747	~~$167.55~~ $140.32	IN STOCK FREE SHIPPING

	Dana Spicer 43205 OUTER STUB AXLE fits 1984 to 2006 Jeep WRANGLER YJ, TJ, XJ, ZJ with DANA 30 Front Axle - Fits 5-760X axle u-joint CLICK HERE for More Details Part Number: 43205	~~$54.99~~ $49.95	IN STOCK

	Dana Spicer 10007804 CHROMOLY Outer Axle Shaft fits 5-760X u-joint with 1.188 cap diameter Dana 30 front 1972 to 1983 Jeep CJ5 and 1976 to 1986 Jeep CJ7 CLICK HERE for More Details Part Number: 10007804	~~$224.94~~ $188.39	IN STOCK FREE SHIPPING

AXLE INNER CJ5, CJ7 Fits 5-760X U-Joint

	Dana Spicer 10007766 CHROMOLY Left Side Inner Axle Shaft fits Dana 30 front 1972 to 1981 Jeep CJ5 and 1976 to 1981 Jeep CJ7 replaces 27941-3X CLICK HERE for More Details Part Number: 10007766	$285.95	FACTORY DIRECT

	Dana Spicer 10007770 CHROMOLY Right side Inner Axle Shaft fits Dana 30 front 1972 to 1981 Jeep CJ5 and 1976 to 1981 Jeep CJ7 replaces 27941-3X CLICK HERE for More Details Part Number: 10007770	~~$326.13~~ $273.13	IN STOCK FREE SHIPPING

	Dana Spicer 10007775 CHROMOLY Left side Inner Axle Shaft fits Dana 30 front 1982 to 1983 Jeep CJ5 and 1982 to 1986 Jeep CJ7 replaces 27941-10X CLICK HERE for More Details Part Number: 10007775	$265.95	IN STOCK FREE SHIPPING

	Dana Spicer 10007777 CHROMOLY Right side Inner Axle Shaft fits Dana 30 front 1982 to 1983 Jeep CJ5 and 1982 to 1986 Jeep CJ7 replaces 27941-9X CLICK HERE for More Details Part Number: 10007777	~~$292.74~~ $245.17	IN STOCK FREE SHIPPING

AXLE INNER YJ, XJ, TJ Fits 5-760X U-Joint

	Dana Spicer 10007743 CHROMOLY Inner Axle Shaft Jeep replaces 73898-1X CLICK HERE for More Details Part Number: 10007743	~~$220.99~~ $185.08	IN STOCK FREE SHIPPING

	Dana Spicer 10007744 CHROMOLY Inner Axle Shaft Jeep replaces 73898-2X CLICK HERE for More Details Part Number: 10007744	$302.95	IN STOCK FREE SHIPPING

	DANA SPICER 73898-1X LEFT INNER AXLE fits 1985 to 2006 Jeep WRANGLER YJ, XJ, TJ with DANA 30 Front 27 Spline CLICK HERE for More Details Part Number: 73898-1X	$123.95	IN STOCK FREE SHIPPING

	DANA SPICER 73898-2X RIGHT INNER AXLE fits 1985 to 2006 Jeep YJ, XJ, TJ with DANA 30 NON Disconnect Front 27 Spline CLICK HERE for More Details Part Number: 73898-2X	$128.96	IN STOCK FREE SHIPPING

AXLES - COMPLETE ASSEMBLY

	ZA W24110 USA Standard 4340 Chromoly replacement axle kit for TJ, XJ, YJ, ZJ Dana 30 front with 27 spline inner axles CLICK HERE for More Details Part Number: ZA W24110	$595.78	FACTORY DIRECT

1984 - 2006 WITHOUT ABS

	Dana Spicer 75814-1X LEFT SIDE Axle Assembly fits Dana 30 front 1985 to 2006 Jeep WRANGLER YJ, TJ, XJ with NO ABS - FREE SHIPPING CLICK HERE for More Details Part Number: 75814-1X	$312.95	SOLD OUT

	Dana Spicer 75814-2X RIGHT SIDE Axle Assembly fits Dana 30 front 1985 to 2006 Jeep WRANGLER YJ, TJ, XJ with NO ABS - FREE SHIPPING CLICK HERE for More Details Part Number: 75814-2X	$312.95	SOLD OUT

1993 - 2006 WITH ABS

	Dana Spicer 75815-1X LEFT SIDE Axle Assembly fits Dana 30 front 1993 to 2006 Jeep YJ, TJ, XJ, ZJ with ABS CLICK HERE for More Details Part Number: 75815-1X	$375.95	IN STOCK FREE SHIPPING

	Dana Spicer 75815-2X RIGHT SIDE Axle Assembly fits Dana 30 front 1993 to 2006 Jeep TJ, XJ, ZJ with ABS CLICK HERE for More Details Part Number: 75815-2X	$375.95	IN STOCK FREE SHIPPING

2007 - 2015

	DANA SPICER 2014616-1 LEFT SIDE HD Axle Assembly fits 2007 to 2017 Jeep WRANGLER JK, UNLIMITED with DANA SUPER 30 Front CLICK HERE for More Details Part Number: 2014616-1	~~$352.64~~ $295.34	IN STOCK FREE SHIPPING

	DANA SPICER 2014616-2 RIGHT SIDE HD Axle Assembly fits 2007 to 2015 Jeep WRANGLER JK, UNLIMITED with DANA SUPER 30 Front CLICK HERE for More Details Part Number: 2014616-2	~~$347.41~~ $325.95	IN STOCK FREE SHIPPING

BALL JOINTS

	Dana Spicer 35417 Adjusting sleeve for Jeep upper ball joint CLICK HERE for More Details Part Number: 35417	$22.95	IN STOCK

	Dana Spicer 40586 Adjusting sleeve for Jeep upper ball joint CLICK HERE for More Details Part Number: 40586	$10.94	IN STOCK

	Dana Spicer 706116X BALL JOINT SET for 1976 to 1998 JEEP CJ5, CJ6, CJ7 and CJ8 with DANA 30 front axle CLICK HERE for More Details Part Number: 706116X	$78.95	IN STOCK

	Dana Spicer 706944X Ball Joint Set fits 1984 to 2006 Jeep YJ, TJ Wrangler, Rubicon and Unlimited, XJ, ZJ with DANA 30 or DANA 44 front CLICK HERE for More Details Part Number: 706944X	$78.49	IN STOCK

BEARINGS

	DT Components DRK-334MK Master Bearing Kit fits Dana 30 Front 1971 to 2000 various Jeep models CLICK HERE for More Details Part Number: DRK-334MK	$115.95	IN STOCK FREE SHIPPING

	DT Components DRK-334TJMK Master Bearing Kit fits Dana 30 Front Jeep Wrangler TJ 1997 to 2006, XJ Cherokee 2000 - 2001, Grand Cherokee 1997 - 1998 CLICK HERE for More Details Part Number: DRK-334TJMK	$129.95	IN STOCK FREE SHIPPING

PINION BEARINGS

INNER

	Dana Spicer 706015X INNER PINION BEARING KIT for Jeep Dana 30 front - HM88649, HM88610 CLICK HERE for More Details Part Number: 706015X	$34.87	IN STOCK

OUTER

	Dana Spicer 706014X OUTER PINION BEARING KIT For Dana 30 Front - M86610, M86647 CLICK HERE for More Details Part Number: 706014X	$62.59	IN STOCK

	Dana Spicer 706030X OUTER PINION BEARING KIT for Jeep Dana 30 front - 02820, 02872 CLICK HERE for More Details Part Number: 706030X	$42.35	SOLD OUT

	Dana Spicer 706894X Roller Bearing cup and cone (1) M86649 (1) M86610 CLICK HERE for More Details Part Number: 706894X	$28.43	IN STOCK

	TIMKEN M86610 Outer pinion bearing fits 1992 and newer Jeep Dana 30 front with collapsible spacer on pinion gear CLICK HERE for More Details Part Number: M86610	$7.55	IN STOCK

	TIMKEN M86649 Outer Pinion Bearing fits 1992 and newer Jeep Dana 30 front with collapsible spacer on pinion gear CLICK HERE for More Details Part Number: M86649	$18.62	IN STOCK

DIFF BEARINGS

	TIMKEN LM501314 Tapered Roller Bearing Cup CLICK HERE for More Details Part Number: LM501314	$8.11	IN STOCK

	TIMKEN LM501349 Tapered Roller Bearing CONE CLICK HERE for More Details Part Number: LM501349	$17.48	IN STOCK

	Dana Spicer 706016X DIFFERENTIAL CARRIER BEARING KIT for Jeep Dana 30 Front NON Disconnect style front axle - LM501349, LM501314 CLICK HERE for More Details Part Number: 706016X	$45.59

SHIMS, BAFFLES and SLINGERS

BAFFLES

	Dana Spicer 32349 Baffle 2.812 inch OD for Inner Pinion Bearing Dana 25, 27, 30, 35, 44, 44 IFS, 50 IFS front end CLICK HERE for More Details Part Number: 32349	$1.95	IN STOCK

SLINGERS

	Dana Spicer 13575 SLINGER for Outer Pinion Bearing 2.875 OD fits Dana 25, 27, 30, 44, 50 CLICK HERE for More Details Part Number: 13575	$0.74	IN STOCK

	Dana Spicer 30764 pinion oil slinger 4.0 inch OD fits Jeep Dana 30 front axle CLICK HERE for More Details Part Number: 30764	$2.25	IN STOCK

SHIMS

	Dana Spicer 701004X SHIM Kit for 1981 to 2006 Jeep DANA 30 Front differential side bearings package of 16 shims CLICK HERE for More Details Part Number: 701004X	$7.64	IN STOCK

	Dana Spicer 706377X Shim Kit includes diff and pinion shims fits Dana 30 front CLICK HERE for More Details Part Number: 706377X	~~$43.95~~ $39.95	IN STOCK

	Dana Spicer 706936X SHIM Kit for Pinion bearings fits Jeep with Dana 30 Front Axle Non Disconnect and Disconnect style CLICK HERE for More Details Part Number: 706936X	~~$59.97~~ $50.22	SOLD OUT

	Dana Spicer 706937X Diff Bearing shim kit for Jeep Dana 30 FRONT Non Disxconnect and Disconnect style axle CLICK HERE for More Details Part Number: 706937X	$68.95	IN STOCK

	Dana Spicer 706938X SHIM Kit for Diff and Pinion bearings fits Jeep with Dana 30 Front Axle Non Disconnect and Disconnect style CLICK HERE for More Details Part Number: 706938X	~~$93.33~~ $78.16	IN STOCK

	Dana Spicer 706087X Diff Case bearing shims and gasket for Dana 30 CLICK HERE for More Details Part Number: 706087X	~~$36.54~~ $30.61	IN STOCK

CRUSH SLEEVE / COLLAPSABLE SPACER

	Dana Spicer 50576 Dana 30 and Dana SUPER 30 Crush Sleeve / Collapsable Spacer CLICK HERE for More Details Part Number: 50576	$3.44	IN STOCK

	Dana Spicer 50614 Crush Sleeve / Collapsible Spacer Fits JEEP JK and WJ with Dana Super 30 front and JEEP JK with Dana 44 FRONT axle CLICK HERE for More Details Part Number: 50614	$3.16	IN STOCK

DIFF PARTS

	Dana Spicer 2007353 Diff COVER kit for Dana 30 front stamped steel OEM fits 1966 to 2018 CLICK HERE for More Details Part Number: 2007353	~~$77.50~~ $64.91	IN STOCK

	Dana Spicer 707486X Diff COVER kit for Dana 30 front stamped steel OEM fits Jeep JK, WJ CLICK HERE for More Details Part Number: 707486X	~~$61.95~~ $51.88	IN STOCK

	Dana Spicer 34279 Diff Cover BOLT 5/16-18 hex head fits Dana 25, 27, 30, Super 30, 35, 44, Chevy 8.2 inch 10 bolt, Chevy 12 Bolt, GM 7.5 and 7.6 inch 10 bolt, GM 8.5 and 8.6 inch 10 bolt, AMC 20 CLICK HERE for More Details Part Number: 34279	$2.25	IN STOCK

	Dana Spicer 36472 Plug for Differential Cover CLICK HERE for More Details Part Number: 36472	$8.83	IN STOCK

	Dana Spicer 43180 Plug for Differential Cover CLICK HERE for More Details Part Number: 43180	$4.95	IN STOCK

	Dana Spicer 41221 RING GEAR BOLT 3/8-24 RH Grade 8 hex head fits Dana 30 front and rear ends CLICK HERE for More Details Part Number: 41221	$0.42	IN STOCK

	Dana Spicer 38615 Loctite SI 5699 Replaced by 70-31414-10 REINZOSIL RTV Silicone Gasket Maker CLICK HERE for More Details Part Number: 38615	$7.65

	Victor Reinz 70-31414-10 Reinzosil RTV Silicone Gasket Maker 2.36 oz. (70 ml) tube CLICK HERE for More Details Part Number: 70-31414-10	$4.94	IN STOCK

	Victor Reinz 70-31414-40 Reinzosil RTV Silicone Gasket Maker 10.48 oz. (310 ml) cartridge for caulking gun CLICK HERE for More Details Part Number: 70-31414-40	$23.64	IN STOCK

DIFF CARRIER

	Dana Spicer 706003X Loaded Open Diff Carrier with Spiders fits 1.18-27 spline axles 3.54 and down ratio Dana 30 Front Jeep CJ 1971 to 1986 CLICK HERE for More Details Part Number: 706003X	~~$196.51~~ $182.67	IN STOCK FREE SHIPPING

	Dana Spicer 706007X Open Diff Case EMPTY No Spiders fits 3.54 and down ratio Dana 30 Front Jeep CJ 1971 to 1986 CLICK HERE for More Details Part Number: 706007X	$112.17	IN STOCK

	Dana Spicer 706008X Open Diff Case EMPTY No Spiders fits 3.73 and up ratio Dana 30 Front Jeep CJ 1971 to 1986 CLICK HERE for More Details Part Number: 706008X	$119.58	IN STOCK FREE SHIPPING

	Dana Spicer 708115 Loaded Open Diff Carrier with Spiders fits 1.18-27 spline axles 3.73 and UP ratio Dana 30 Front replaces old number 706004X fits Jeep CJ 1971 to 1986 CLICK HERE for More Details Part Number: 708115	$253.43	IN STOCK FREE SHIPPING

SPIDER GEARS

	Dana Spicer 13449 ROLL PIN for Diff Spider Cross shaft fits Dana 28 IFS, 30, 35, 44, 36 ICA, 44 ICA, 44 IFS CLICK HERE for More Details Part Number: 13449	$0.45	IN STOCK

	Dana Spicer 706010X INNER GEAR KIT SPIDER GEARS fits 1971 to 1986 Jeep CJ Dana 30 FRONT differential with 27 spline axles CLICK HERE for More Details Part Number: 706010X	~~$122.53~~ $102.62	IN STOCK FREE SHIPPING

	Dana SVL 10020714 INNER GEAR KIT SPIDER GEARS fits 1971 to 1986 JEEP CJ Dana 30 FRONT differential with 27 spline axles CLICK HERE for More Details Part Number: 10020714	$76.45	SOLD OUT

	Dana Spicer 41648 Spider Gear Cross Shaft for Jeep with Dana 30 front Open diff carrier CLICK HERE for More Details Part Number: 41648	$22.64	IN STOCK

RING AND PINION GEAR SETS

STANDARD ROTATION

	Dana Spicer 706503-3X Ring and Pinion Gear set kit standard rotation 3.73 ratio for Dana 30 FRONT 1971 to 1986 Jeep CJ CLICK HERE for More Details Part Number: 706503-3X	~~$586.43~~ $491.14	SOLD OUT

	Dana Spicer 706503-4X Ring and Pinion Gear set kit standard rotation 4.10 ratio for Dana 30 FRONT 1971 to 1986 Jeep CJ CLICK HERE for More Details Part Number: 706503-4X	~~$282.79~~ $265.95	FACTORY DIRECT

REVERSE ROTATION

	Dana Spicer 706930-2X Ring and Pinion Gear set kit REVERSE rotation 3.07 ratio for Jeep XJ, YJ with Dana 30 FRONT CLICK HERE for More Details Part Number: 706930-2X	~~$899.72~~ $757.95

	Dana Spicer 706930-8X Ring and Pinion Gear set kit REVERSE rotation 3.55 ratio for Jeep XJ, YJ with Dana 30 FRONT CLICK HERE for More Details Part Number: 706930-8X	$494.50

	Dana Spicer 706930-5X Ring and Pinion Gear set kit REVERSE rotation 3.73 ratio for Jeep XJ, YJ with Dana 30 FRONT CLICK HERE for More Details Part Number: 706930-5X	$360.51

	Dana Spicer 706930-4X Ring and Pinion Gear set kit REVERSE rotation 4.10 ratio for Jeep XJ, YJ with Dana 30 FRONT CLICK HERE for More Details Part Number: 706930-4X	$313.80

	Dana Spicer 706930-6X Ring and Pinion Gear set kit REVERSE rotation 4.56 ratio for Jeep XJ, YJ with Dana 30 FRONT CLICK HERE for More Details Part Number: 706930-6X	$405.25

PINION NUT and WASHER

	Dana 30 Pinion WASHER CLICK HERE for More Details Part Number: 30186	$0.40	IN STOCK

	DANA SPICER 30185 Dana 30 Pinion NUT CLICK HERE for More Details Part Number: 30185	$0.95	IN STOCK

	Dana Spicer 44189 Pinion Nut fits 2007 to 2016 JEEP Wrangler JK with DANA Super 30 or DANA 44 FRONT END CLICK HERE for More Details Part Number: 44189	$2.95	IN STOCK

PINION YOKE

	Dana Spicer 2-4-8091X Pinion Yoke 1310 series fits Dana 30, Dana 44 with 26 spline pinion CLICK HERE for More Details Part Number: 2-4-8091X	~~$54.28~~ $49.65	IN STOCK

	Neapco N2-4-8091X Pinion Yoke 1310 series fits Dana 30, Dana 44 with 26 spline pinion CLICK HERE for More Details Part Number: N2-4-8091X	~~$82.55~~ $78.62	IN STOCK

	6258114 Pinion Yoke 1330 series High Angle fits DANA 30 with 26 spline pinion 3.732 tall yoke CLICK HERE for More Details Part Number: 6258114	$72.95	SOLD OUT

PINION SEAL

	Dana Spicer 44895 Pinion Seal fits JEEP DANA 30 Front CLICK HERE for More Details Part Number: 44895	$7.95	IN STOCK

	Dana Spicer 2004670 Pinion Seal fits 2007 to 2018 JEEP Wrangler JK with DANA Super 30 or DANA 44 FRONT END CLICK HERE for More Details Part Number: 2004670	$13.95	IN STOCK

TUBE SEAL

	Dana Spicer 46470 TUBE SEAL 2.125 OD fits Right and Left Side 1972 to 1986 Jeep CJ, 1997 to 2006 Jeep TJ, 2007 to 2011 Jeep JK, 1993 to 1998 Jeep ZJ, 1999 to 2001 Jeep XJ with Dana 30 Front Axle - NON Disconnect style CLICK HERE for More Details Part Number: 46470	$5.20	IN STOCK

WHEEL BEARING / SPINDLE PARTS

WHEEL BEARING

	Dana Spicer 706111X Outer Wheel Bearing Kit includes LM501349 and LM501310 for Jeep CJ 1971 to 1986 with separate inner and outer wheel bearings CLICK HERE for More Details Part Number: 706111X	$25.52	IN STOCK

	Timken Seal 4131 Front wheel hub seal fits Jeep CJ 1976 to 1983 CLICK HERE for More Details Part Number: 4131	$15.95	IN STOCK

	Timken Seal 493637 Front wheel hub seal fits Jeep CJ 1984 to 1986 CLICK HERE for More Details Part Number: 493637	$12.15	SOLD OUT

	TIMKEN Bearings SET 45 - Includes LM501349 CONE LM501310 CUP fits 1971 to 1986 Jeep CJ CLICK HERE for More Details Part Number: SET 45	$21.54	IN STOCK

	TIMKEN Bearings SET 47 - Includes LM102949 CONE LM102910 CUP Inner wheel hub bearing fits 1976 to 1986 Jeep CJ CLICK HERE for More Details Part Number: SET 47	$23.95	IN STOCK

	TIMKEN LM501349 Outer Wheel Bearing Cone for Jeep CJ 1971 to 1986 with separate inner and outer wheel bearings CLICK HERE for More Details Part Number: LM501349	$17.48	IN STOCK

	TIMKEN LM501310 Outer Wheel Bearing Cup for Jeep CJ 1971 to 1986 with separate inner and outer wheel bearings CLICK HERE for More Details Part Number: LM501310	$7.41	IN STOCK

SPINDLE PARTS

	.375-24 Cone Lock NUT 3/8 inch fine thread self locking nut zinc plated CLICK HERE for More Details Part Number: CLN375-24	$0.45	IN STOCK

	Dana Spicer 36326-1 Spindle stud for Jeep Dana 30 front .375-24 x 1.312 CLICK HERE for More Details Part Number: 36326-1	$3.59	SOLD OUT

	Dana Spicer 36361 V-Ring Rubber Seal fits Dana 30, 44 front spindle CLICK HERE for More Details Part Number: 36361	$5.95	IN STOCK

	Dana Spicer 38106 thrust washer for inner bearing on front spindle CLICK HERE for More Details Part Number: 38106	$2.95	IN STOCK

	Dana Spicer 38128 V-Ring Rubber Seal fits Dana 30, 44 front spindle CLICK HERE for More Details Part Number: 38128	$5.95	IN STOCK

	DANA SPICER 550759 Needle Bearing fits front spindle Jeep, Chevy, Ford, Dodge and IH with Dana 30 or Dana 44 front CLICK HERE for More Details Part Number: 550759	$12.39	IN STOCK

	DANA SPICER 706527X Spindle Bearing and Seal Set fits DANA 30 FRONT CLICK HERE for More Details Part Number: 706527X	$15.95	IN STOCK
