We have designed the best measuring sheets in the industry. These drawings will guide you to measure your application correctly to ensure proper fit and performance each and every time.
IT'S EASY TO GET IT RIGHT THE FIRST TIME...
Place two safety stands under the differential housing tubes to support vehicle high enough to get under and do a good job. Measuring the overall length correctly is very important.
PRINT it OUT and fill in ALL the answers and please be sure to MEASURE EXACTLY as it shows.
Diagram "B" & Diagram "C" are USED MOST OFTEN for Street Rods, Race Cars and 4x4 trucks.
Remember always measure your vehicle with the rear tires on the ground OR the rear end on 2 safety stands. It is important to have the suspension in this position to measure correctly.
DO NOT MEASURE with the suspension hanging!!! If measuring 4X4 trucks you must have both the front and rear tires on the ground or the axles supported on safety stands.
Each Diagram will give you Spaces to Fill in and Choices to Circle for the different possibilities
Please remember we will need All the Questions Answered for the DIAGRAM you are using to quote a price or to build a shaft.
Call 716-875-6640 for measuring questions. Call 800-955-1872 to place your order.
For additional info in measuring the rear u-joint please see
Diagram "B" Diagram "K" - some Ford vehicles use Diagram "K"
Diagram "B" Diagram "G" Diagram "K"
Most 4X4 Front shafts use
Most 4x4 Rear shafts use
If you cannot VIEW or PRINT the MEASURING SHEET
Please send us an E-MAIL requesting the measuring sheet and give us your complete name and address and we will be happy to send it out by US. mail.
If you need immediate assistance Please call (716) 875-6640 and one of our tech advisors will instruct you on how to measure. For business hours see our contact us page.
