Denny's Driveshaft builds custom steel and aluminum driveshafts for your high performance car, street rod, race car, van, pick up or 4x4 truck

Dana Spicer 3-53-1191 MIDSHIP SPLINE Fits 4.0 inch .083 wall tube 1.562 inch Diameter with 16 Splines
Part #:
3-53-1191
Your Cost $68.26

DANA SPICER 3-53-1191

  • MIDSHIP SPLINE
  • Use with Center Support Bearing


Spicer
Dana Spicer 3-53-1191 MIDSHIP SPLINE Fits 4.0 inch .083 wall tube 1.562 inch Diameter with 16 Splines
Dana Spicer 3-53-1191 MIDSHIP SPLINE Fits 4.0 inch .083 wall tubing 1.562 inch Diameter with 16 Splines
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $68.26

DANA SPICER 3-53-1191

  • MIDSHIP SPLINE
  • Use with Center Support Bearing
  • Fits any series 16 Spline SLIP YOKE designed for 1.562 inch diameter spline
    • Fits TUBE DIAMETER = 4.0 inch OUTSIDE TUBE Diameter
    • Fits TUBE WALL THICKNESS =  .083 inch Tube wall thickness
    • Major SPLINE Diameter = 1.562
    • SPLINES = 16
    • STYLE = 1
    • B = 1.940
    • C = 1.575
    • G = .812
    • K = 8.531
    • L = 5.938
    • Y = 7.470
  • SPECIAL NOTES:
    • Blue GLIDECOAT on Spline for smooth operation and long life (DO NOT REMOVE this coating)



CLICK HERE : For ALL DANA SPICER Spline Part Numbers, Specifications and Dimensions

Dana Spicer 3-53-1191 MIDSHIP SPLINE Fits 4.0 inch .083 wall tube 1.562 inch Diameter with 16 Splines

Dana Spicer 3-53-1191 MIDSHIP SPLINE Fits 4.0 inch .083 wall tubing 1.562 inch Diameter with 16 Splines
