Denny's Driveshaft builds custom steel and aluminum driveshafts for your high performance car, street rod, race car, van, pick up or 4x4 truck

Dana Spicer 3-53-07832 MIDSHIP SPLINE Fits 3.5 inch .083 wall tube 1.562 inch Diameter with 16 Splines
Part Number:
3-53-07832


UPC:
023913218188
Your Cost $121.22 Sale Price $108.88
You Save $12.34
STATUS:  IN STOCK - FREE SHIPPING

DANA SPICER 3-53-07832

  • MIDSHIP SPLINE
  • Use with Center Support Bearing

Spicer
Dana Spicer 3-53-07832 MIDSHIP SPLINE Fits 3.5 inch .083 wall tube 1.562 inch Diameter with 16 Splines
Dana Spicer 3-53-07832 MIDSHIP SPLINE Fits 3.5 inch .083 wall tubing 1.562 inch Diameter with 16 Splines
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK - FREE SHIPPING
YOUR COST:  $121.22 Sale Price $108.88
You Save $12.34

DANA SPICER 3-53-07832

  • MIDSHIP SPLINE
  • Use with Center Support Bearing
  • Fits any series 16 Spline SLIP YOKE designed for 1.562 inch diameter spline
    • Fits TUBE DIAMETER = 3.5 inch OUTSIDE TUBE Diameter
    • Fits TUBE WALL THICKNESS =  .083 inch Tube wall thickness
    • Major SPLINE Diameter = 1.562
    • SPLINES = 16
    • STYLE = 2
    • B = 1.940
    • C = 1.575
    • G = .810
    • K = 8.578
    • L = 3.000
    • Y = 7.470
  • SPECIAL NOTES:
    • Blue GLIDECOAT on Spline for smooth operation and long life (DO NOT REMOVE this coating)
    • Replaces Dana Spicer 5007832



CLICK HERE : For ALL DANA SPICER Spline Part Numbers, Specifications and Dimensions

Dana Spicer 3-53-07832 MIDSHIP SPLINE Fits 3.5 inch .083 wall tube 1.562 inch Diameter with 16 Splines

Dana Spicer 3-53-07832 MIDSHIP SPLINE Fits 3.5 inch .083 wall tubing 1.562 inch Diameter with 16 Splines
