Dana Spicer 2-3-4911X - Muncie M20 M21 & M22 Transmission Slip yoke 1310 27 spline 5 inch
2-3-4911X
DANA SPICER 2-3-4911X
1310 Series transmission slip yoke to fit Muncie M20 & M21 and M22 with 27 spline output shaft. Overall length is 5 inches and is 1/2 inch shorter and has less operating angle than part number 2-3-6081X
Limited Supply: only 2 remaining
Pricing:
$187.95
Description
DANA SPICER 2-3-4911X
1310 Series transmission slip yoke to fit Muncie M20 & M21 and M22 with 27 spline output shaft. Overall length is 5 inches and is 1/2 inch shorter and has less operating angle than part number 2-3-6081X
- Length to center of u-joint... Dimension #1 = 5 inches
- Barrel Diameter... Dimension #2 = 1 1/2 inches
- Barrel Length... Dimension #3 = 3 5/8 inches
- U-joint cap diameter... Dimension #4 = 1 1/16 inches
- U-joint width... Dimension #5 = 3 7/32 inches
- Series... 1310
- Spline count... 27
Details
- 2-3-4911X
- 2-3-4911X
- Spicer
- Available
- New
Categories
- Driveline Parts - Slip Yokes - SLIP YOKES - For Automatic and Manual Transmission
- Slip Yokes - SLIP YOKES - For Automatic and Manual Transmission - Muncie and Auto Gear
- SLIP YOKES - For Automatic and Manual Transmission - Muncie and Auto Gear - ALL with 27 SPLINE Rear Output
- Muncie and Auto Gear - ALL with 27 SPLINE Rear Output - Fits 3 7/32 by 1 1/16 U-Joint - 1310 Series
Shipping Information
- Item Requires Shipping
- 4.5 lbs.
- W6.0000” x H5.0000” x L8.0000”
- FREE SHIPPING ON PARTS ORDERS OVER $99
