Dana Spicer 29833-2X Left Side Complete axle assembly 1973 to 1980 GM Truck & Blazer with Dana 44 - FREE SHIPPING
Diagram Number: 47
29833-2X
DANA SPICER 29833-2X
- General Motors Truck & Blazer 1973 to 1980 with Dana 44
- LEFT SIDE COMPLETE AXLE ASSEMBLY with 30 spline inner ready to bolt in
- DRIVERS SIDE
Limited Supply: only 1 remaining
Shipping: FREE GROUND Shipping**
**Free Ground Shipping to lower 48 States ONLY...Alaska and Hawaii at reduced rates.
Pricing:
$525.95
Description
DANA SPICER 29833-2X
- General Motors Truck & Blazer 1973, 1974, 1975, 1976, 1977, 1978, 1979, 1980 with Dana 44 Front Axle
- LEFT SIDE COMPLETE AXLE ASSEMBLY with 30 spline inner
- DRIVERS SIDE
- Genuine DANA SPICER Replacement FULLY ASSEMBLED Front Axle Shaft and ready to bolt in
- INCLUDES
- Seal retainer
- Outer Axle
- Inner Axle
- Universal Joint
LEFT SIDE COMPLETE AXLE ASSEMBLY...Inner, Outer and U-joint
- Dimension "A" = 46.07 inches overall
- Dimension "B1" = 19 Spline - 1.25 inch diameter
- Dimension "B" = 9.94 inches
- Dimension "C1" = 30 Spline -1.31 inch diameter
- Dimension "C" = 36.13 inches
- Comes complete with Spicer 5-760X Universal Joint.
Details
- 29833-2X
- 29833-2X
- Spicer
- Available
- New
Shipping Information
- Item Requires Shipping
- 25.0 lbs.
- W6.0000” x H5.0000” x L48.0000”
