Dana Spicer 3-53-1181 MIDSHIP SPLINE Fits 3.0 inch .083 wall tube 1.375 inch Diameter with 31/32 Splines

DANA SPICER 3-53-1181

• MIDSHIP SPLINE
• Designed for use with Center Support Bearing
• Can also be used without center support bearing on a 2 joint spline and slip driveshaft

• Fits any series 31 based on 32 Spline SLIP YOKE designed for 1.375 inch diameter spline
  • Fits TUBE DIAMETER = 3.0 inch OUTSIDE TUBE Diameter
  • Fits TUBE WALL THICKNESS =  .083 inch Tube wall thickness
  • Major SPLINE Diameter = 1.375
  • SPLINES = 31/32
  • STYLE = 2
  • B = 1.719
  • C = 1.378
  • G = 1.125
  • K = 8.812
  • L = 3.344
  • Y = 7.469
• SPECIAL NOTES: Steel splines no coating
