DANA 44 - W150, W200, W250 DISCONNECT FRONT - DODGE

DANA 44 DISCONNECT Front Axle

DODGE W150, W200, W250 4x4 with DISCONNECT on DRIVERS SIDE (Left Side)

1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1993-1/2

Dodge W150, W200, W250 Dana 44 Disconnect front axle exploded view

 Diagram # Part # Description  Diagram # Part # Description
 1  ******  Housing - For reference only  51  38128  Rubber Seal
 2  Multiple  Ring and Pinion Gear Set  52  36361  Rubber Seal
 3  30764  Slinger for inner pinion brg  53  38106  Spacer / thrust washer
 4  706031X  INNER Pinion Bearing Kit  54  550759  Inner spindle needle bearing
 5  Multiple  SHIMS Kit - Inner Pinion Bearing  55  706570X  Spindle
 6  30765  Slinger for inner pinion brg  56  See 46  Nut for spindle stud
 7  Multiple  SHIMS Kit - Outer Pinion Bearing  57  4250  Hub inner seal
 8  706030X  OUTER Pinion Bearing Kit  58  Multiple  Inner Wheel Bearing
 9  13575  Slinger for outer pinion brg  59    Hub
 10  44895  Pinion Seal  60    Outer Wheel Bearing
 11  Multiple  Pinion Yoke  61  21588X  Lock Nut with PIN
 12  ******  Shield ...see pinion yoke  62  36569  Washer
 13  30186  Washer for Pinion nut  63  31139  Lock Nut
 14  30185  Pinion Nut  65    Spacer
 15  Multiple  Diff Cover  66  42667  Drive Gear
 16  Multiple  Gasket / Sealant  67  31624  Snap Ring
 17  36472  Plug  68  44328  Cap
 18  34279  Cover Bolt  69 - 73
 19  *******  Diff Bearing Cap  70
 20  48632-1  Bolt - Diff Brg Cap  71  41594  Brake line clip
 21  706032X  Diff Side Bearings  72  42206  Shield
 22  Multiple  SHIM Kit - Diff Brg  73    Motor Assembly
 23  Multiple  Diff Case  74  620980  O-Ring
 24  41221  Ring Gear Bolt  75  42208  Cover - Disconnect Housing
 25  Multiple  Large Spider Gear  76  44476  O-Ring
 26  Multiple  Small Spider Gear  77
 27  Multiple  Thrustwasher for Sm Spider  78  621097  Snap Ring
 28  Multiple  Thrustwasher for Lg Spider  79  620979  Snap Ring
 29  39194  Diff Cross PIN  80  42585  Shift Fork
 30  13449  Lock pin  81  621059  Clip for shift fork
 31  620216  TUBE SEAL - RIGHT  82  42998  Clutch Collar
 32 - 38  706116X  Ball Joint Set  83  41494  Gasket
 39  ******  Stop Screw  84  565985  Bushing / Bearing
 40  ******  Jam Nut  85  Multiple  Inner Axle Shaft LEFT
 41 - 43      86  43154  Tube Seal LEFT
 44 - 45  ******  Knuckle  87  566008  Bushing / Bearing
 46  36326-2  Spindle Stud  88  75265X  Intermediate Axle Shaft LEFT
 47  Multiple  Axle  89  42570  Snap Ring
 48  40191  Seal - Outer TUBE LEFT
 49  565983  Bearing - Outer TUBE LEFT
 50  36364  Outer Axle Seal Retainer



DANA 44 - W150, W200, W250 DISCONNECT FRONT - DODGE

AXLES

AXLES - OUTER

Dana Spicer 10007803 CHROMOLY OUTER AXLE fits 1991 to 1991-1/2 DODGE W150, W200, W250 with DANA 44 Disconnect Front Axle CLICK HERE for More Details Part Number: 10007803
Diagram Number:
47-OUTER
$224.94
$188.39
IN STOCK
FREE SHIPPING

AXLES - PASSENGER SIDE INNER

AXLES - DRIVERS SIDE INNER DISCONNECT

SNAP RING FOR OUTER AXLE

AXLE U-JOINTS

BALL JOINTS

DISCONNECT PARTS

Dana Spicer 621097 Shift Fork Snap Ring Fits Dana 44 Disconnect Front Axle CLICK HERE for More Details Part Number: 621097
Diagram Number:
78
$3.10
IN STOCK

BEARINGS and SHIMS

PINION BEARINGS

Dana Spicer 30764 pinion oil slinger 4.0 inch OD fits Dana 44 CLICK HERE for More Details Part Number: 30764
Diagram Number:
3
$2.25
IN STOCK

DIFF BEARINGS

SHIMS

PINION NUT and WASHER

PINION SEAL

DIFF COVER

Dana Spicer 34279 Diff Cover BOLT 5/16-18 hex head fits Dana 44 CLICK HERE for More Details Part Number: 34279
Diagram Number:
18
$2.25
IN STOCK
Victor Reinz 70-31414-10 Reinzosil RTV Silicone Gasket Maker 2.36 oz. (70 ml) tube CLICK HERE for More Details Part Number: 70-31414-10
Diagram Number:
16
$4.94
IN STOCK

SPINDLE BEARING AND SEALS

Dana Spicer 36326-2 Spindle Stud Bolt and Nut 3/8 - 24 CLICK HERE for More Details Part Number: 36326-2
Diagram Number:
46
$1.79
IN STOCK

SPINDLE NUT

DANA SPICER 36569 Spindle Washer Locking Ring with holes CLICK HERE for More Details Part Number: 36569
Diagram Number:
62
$2.54
IN STOCK

TUBE SEAL

CROSS SHAFT, ROLL PIN

Dana Spicer 39194 Diff Cross Shaft PIN fits OPEN DIFF DANA 44 FRONT CLICK HERE for More Details Part Number: 39194
Diagram Number:
29
$12.38
IN STOCK

RING GEAR BOLTS

Dana Spicer 41221 RING GEAR BOLT .375-24 thread fits Dana 44 Front DIFF CLICK HERE for More Details Part Number: 41221
Diagram Number:
24
$0.42
IN STOCK

HUB CAP / GEAR

Dana Spicer 42667 AXLE DRIVE GEAR for front wheel hub fits Dodge with Dana 44 front CLICK HERE for More Details Part Number: 42667
Diagram Number:
66
$63.10
$52.85
IN STOCK
Dana Spicer 44328 Cap for front wheel hub fits Dodge Dana 44 CLICK HERE for More Details Part Number: 44328
Diagram Number:
68
$14.69
IN STOCK

WHEEL HUB SEAL - FRONT

Timken 4250 Front Wheel Seal CLICK HERE for More Details Part Number: 4250
Diagram Number:
57
$9.95
IN STOCK

LEFT SIDE TUBE BEARING/SEAL
