DANA SPICER 4-1-2701 Companion Flange 1410/1480/1550 Series 1.500 x 10 spline with 2.125 Hub

292564

DANA SPICER 4-1-2701

  • COMPANION FLANGE
  • 1410/1480/1550 Series
  • 1.500 - 10 SPLINE
Not Available
Shipping: >>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
Pricing: $270.43

Description

DANA SPICER 4-1-2701

  • COMPANION FLANGE
  • 1410/1480/1550 Series



Companion Flanges - Splined Hole Model/Part #:  4-1-2701
D.) Spline OD 1.500
No. of Splines 10
C) Pilot Dia. M=male F=female 3.750F
B) Bolt Circle Dia. 4.750
Bolt Hole Dia. (D-drilled T=tapped) .500-D
No. of Holes 4
Drum Pilot Dia. 3.750
E) Hub Dia. 2.125
F) Len thru Hole 2.000
G) Flg. Face to Hub End 2.625
Figure 1
Slinger Part No.
Series 1410/1480/1550



Details

  • 292564
  • 292564
  • Spicer
  • Temporarily Not Available
  • New

Categories

Shipping Information

  • Item Requires Shipping
  • 4.0 lbs.
  • W5.0000” x H5.0000” x L5.0000”
