Denny's Driveshaft builds custom steel and aluminum driveshafts for your high performance car, street rod, race car, van, pick up or 4x4 truck

DANA SPICER 3-1-3431 Companion Flange 1350/1410 Series 1.500 x 10 spline with 2.00 Hub .310 counterbore
Part Number:
3-1-3431


UPC:
023913230111
Your Cost $234.63 Sale Price $210.66
You Save $23.97
Sorry, sold out
STATUS:  FACTORY BACK ORDER at this time

DANA SPICER 3-1-3431

  • COMPANION FLANGE
  • 1350/1410 Series
  • 1.500 - 10 SPLINE
  • .310 counterbore at end of hub
Spicer
DANA SPICER 3-1-3431 Companion Flange 1350/1410 Series 1.500 x 10 spline with 2.00 Hub .310 counterbore
DANA SPICER 3-1-3431 Companion Flange 1350/1410 Series 1.500 x 10 spline with 2.00 Hub .310 counterbore
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY BACK ORDER at this time
YOUR COST:  $234.63 Sale Price $210.66
You Save $23.97

DANA SPICER 3-1-3431

  • COMPANION FLANGE
  • 1350/1410 Series



Companion Flanges - Splined Hole Model/Part #:  3-1-3431
D.) Spline OD 1.500
No. of Splines 10
C) Pilot Dia. M=male F=female 2.750F
B) Bolt Circle Dia. 3.750
Bolt Hole Dia. (D-drilled T=tapped) .438-D
No. of Holes 4
Drum Pilot Dia. 3.112
E) Hub Dia. 2.000
F) Len thru Hole 2.188
G) Flg. Face to Hub End 2.906
Figure 1
Slinger Part No.
Series 1350/1410


.310 deep counterbore at hub end
