Dana Spicer 3-40-1871 SPLINE Fits 3.5 inch .083 wall Driveshaft tube 1.562 inch Diameter with 16 Splines
3-40-1871
DANA SPICER 3-40-1871 SPLINE
Fits 3.5 inch .083 wall Driveshaft tubing
1.562 inch Diameter with 16 Splines
Limited Supply: only 2 remaining
Pricing:
$103.95
Description
DANA SPICER SPLINE 3-40-1871
- Fits any series 16 Spline SLIP YOKE designed for 1.562 inch diameter spline
- Fits TUBE DIAMETER = 3.5 inch OUTSIDE TUBE Diameter
- Fits TUBE WALL THICKNESS = .083 inch Tube wall thickness
- Major SPLINE Diameter = 1.562
- SPLINES = 16
- K = 8.750
- L = 3.0
- R = 7.810
Details
- 3-40-1871
- 3-40-1871
- Spicer
- Available
- New
Categories
- Driveline Parts - BUILD IT YOURSELF - PARTS LISTS - 1480 SPLINE and SLIP DRIVESHAFT
- BUILD IT YOURSELF - PARTS LISTS - 1480 SPLINE and SLIP DRIVESHAFT - BUILD 1480 SERIES with 3.5 INCH DIAMETER TUBE
- 1480 SPLINE and SLIP DRIVESHAFT - BUILD 1480 SERIES with 3.5 INCH DIAMETER TUBE - SPLINE and SLIP
- Driveline Parts - BUILD IT YOURSELF - PARTS LISTS
Shipping Information
- Item Requires Shipping
- 6.0 lbs.
- W4.0000” x H4.0000” x L9.0000”
- FREE SHIPPING ON PARTS ORDERS OVER $99
