DANA SPICER 2-4-2611-1X End Yoke 1310 series 1.250 - 10 spline fits Dana 60, 70 with 10 spline pinion

2-4-2611-1X

DANA SPICER 2-4-2611-1X

  • Fits Dana 60, 70 with 10 spline pinion
  • 1.250 - 10 spline
  • 1310 series
  • Strap and Bolt style

Limited Supply: only 1 remaining
Pricing: $92.95

Customize Your Item

- -
 * required
Qty:

Description

DANA SPICER 2-4-2611-1X

Fits Dana 60, 70 with 10 spline pinion

  • Strap and Bolt Style
  • Fits 1310 Series universal joint 3 7/32 inches wide with 1 1/16 inch bearing caps.
  • 10 splines
  • SPLINE DIAMETER = 1.250
  • D = 1.062
  • E = 3.219
  • Q = 1.500
  • R = 1.875
  • S = 2.938

Details

  • 2-4-2611-1X
  • 2-4-2611-1X
  • Spicer
  • Available
  • New

Categories

Shipping Information

  • Item Requires Shipping
  • 2.1 lbs.
  • W6.0000” x H5.0000” x L5.0000”
