Dana Spicer 3-4-8681-1 Pinion Yoke 1350 Series 30 spline fits 1981 to 1997 Chevy and GMC 9.5 inch 14 Bolt rear end
Part #:
3-4-8681-1
Your Cost $61.95

Dana Spicer 3-4-8681-1

  • Strap and bolt style

PINION YOKE

  • 1350 series
  • Fits Chevy and GMC 9.5 inch 14 bolt rear end.... with "C" clip axles
    • 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997
  • DOES NOT FIT 14 bolt Full Floater with bolt in axles
  • DOES NOT have a dust shield
    • See 3-4-8691-1X at bottom of page for same yoke with dust shield
  • Use with seal part number 3896 ... see bottom of this page
  • Use with strap and bolt set 3-70-28X  ... see bottom of page

DIMENSIONS

  • 1350 series
  • 30 SPLINE
  • SPLINE OD = 1.312
  • D = 1.188
  • E = 3.625
  • Q = 1.156
  • R = 1.938
  • S = 3.125

Spicer
Dana Spicer 3-4-8681-1 Pinion Yoke 1350 Series 30 spline fits 1981 to 1997 Chevy and GMC 9.5 inch 14 Bolt rear end
Dana Spicer 3-4-8681-1 Pinion Yoke 1350 Series 30 spline fits 1981 to 1997 Chevy and GMC 9.5 inch 14 Bolt rear end
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $61.95

Dana Spicer 3-4-8681-1

  • Strap and bolt style

PINION YOKE

  • 1350 series
  • Fits Chevy and GMC 9.5 inch 14 bolt rear end.... with "C" clip axles
    • 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997
  • DOES NOT FIT 14 bolt Full Floater with bolt in axles
  • DOES NOT have a dust shield
    • See 3-4-8691-1X at bottom of page for same yoke with dust shield
  • Use with seal part number 3896 ... see bottom of this page
  • Use with strap and bolt set 3-70-28X  ... see bottom of page

DIMENSIONS

  • 1350 series
  • 30 SPLINE
  • SPLINE OD = 1.312
  • D = 1.188
  • E = 3.625
  • Q = 1.156
  • R = 1.938
  • S = 3.125
