Driveshaft and Driveline Parts > SPINDLES > FORD > with DANA 44 IFS Front Axle

Dana Spicer 707178X SPINDLE fits 1980 to 1992 Ford Bronco, F150 with DANA 44 IFS front axle
Part #:
707178X
Your Cost $198.95
Sorry, Not Available Right Now

DANA SPICER 707178X

  • SPINDLE
    • Replaces old number Dana Spicer 41928
    • Comes with Dana Spicer 706527x spindle bearing, spindle seals and 36364 seal retainer
      • Ready to bolt in....Inner spindle needle bearing has been pressed in place at the proper depth
  • Fits Ford Bronco with Dana 44 IFS front axle
    • 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992
  • Fits Ford F150 with Dana 44 IFS front axle
    • 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992



Spicer
Dana Spicer 707178X SPINDLE fits 1980 to 1992 Ford Bronco, F150 with DANA 44 IFS front axle
Dana Spicer 707178X SPINDLE fits 1980 to 1992 Ford Bronco, F150 with DANA 44 IFS front axle
Click for Larger Photo
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  SOLD OUT...More Coming Soon
YOUR COST:  $198.95

DANA SPICER 707178X

  • SPINDLE
    • Replaces old number Dana Spicer 41928
    • Comes with Dana Spicer 706527x spindle bearing, spindle seals and 36364 seal retainer
      • Ready to bolt in....Inner spindle needle bearing has been pressed in place at the proper depth
  • Fits Ford Bronco with Dana 44 IFS front axle
    • 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992
  • Fits Ford F150 with Dana 44 IFS front axle
    • 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992

DIMENSIONS:

  • KEYWAY SLOT = .312 in. wide (5/16 inch)
  • BORE ID = 1.300 inches
  • A = 1.622 in. OD for Outer Wheel Bearing
  • B = 1.778 in. OD for Inner Wheel Bearing
  • C = 2-1/2 in. OD for Seal
  • D = 3-3/8 in.
  • E = 1/2 in.
  • F = 3/8 in.
  • G = 5-7/16 in.
  • H = 6-1/4 in.
  • K = 4-3/4 in.
  • Bolt Holes = 6
  • Bolt Hole Diameter = .400 in.

How to Measure a 4X4 Front Axle Spindle at Denny's Driveshafts
