Denny's Driveshaft builds custom steel and aluminum driveshafts for your high performance car, street rod, race car, van, pick up or 4x4 truck

Dana Spicer 706528X SPINDLE SMALL Bearing style fits 1973 to 1976-1/2 Chevy 1/2 ton K5, K10, Suburban and GMC 1/2 ton Jimmy, K15 with DANA 44 Front axle
Part #:
706528X
Your Cost $179.95

DANA SPICER 706528X

  • SPINDLE
  • Fits Chevy 1/2 ton K5 Blazer, K10, and Suburban with DANA 44 front axle
    • 1973, 1974, 1975, 1976, 1976-1/2
  • Fits GMC 1/2 ton K5 Jimmy, K15 with DANA 44 front axle
    • 1973, 1974, 1975, 1976, 1976-1/2
  • 6 Bolt Holes
  • Small Bearing style



Spicer
Dana Spicer 706528X SPINDLE SMALL Bearing style fits 1973 to 1976-1/2 Chevy 1/2 ton K5, K10, Suburban and GMC 1/2 ton Jimmy, K15 with DANA 44 Front axle
Dana Spicer 706528X SPINDLE SMALL Bearing style fits 1973 to 1976-1/2 Chevy 1/2 ton K5, K10, Suburban and GMC 1/2 ton Jimmy, K15 with DANA 44 Front axle
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK - FREE SHIPPING
YOUR COST:  $179.95

DANA SPICER 706528X

  • SPINDLE
  • Fits Chevy 1/2 ton K5 Blazer, K10, and Suburban with DANA 44 front axle
    • 1973, 1974, 1975, 1976, 1976-1/2
  • Fits GMC 1/2 ton K5 Jimmy, K15 with DANA 44 front axle
    • 1973, 1974, 1975, 1976, 1976-1/2
  • 6 Bolt Holes
  • Small Bearing style

DIMENSIONS:

  • KEYWAY SLOT = .250 in. wide (1/4 inch)
  • BORE ID = 1.300 inches
  • A = 1.622 in. OD for Outer Wheel Bearing
  • B = 1.778 in. OD for Inner Wheel Bearing
  • C = 2-1/2 in. OD for Seal
  • D = 3-3/8 in.
  • E = 7/16 in.
  • F = 3/8 in.
  • G = 5-5/8 in.
  • H = 6-1/2 in.
  • K = 4-3/4 in.
  • Bolt Holes = 6
  • Bolt Hole Diameter = .400 in.

How to Measure a 4X4 Front Axle Spindle at Denny's Driveshafts
