Dana Spicer 706528X SPINDLE fits 1974, 1975, 1976 Jeep Wagoneer and Cherokee with Disc Brakes Dana 44 front axle

DANA SPICER 706528X

• SPINDLE with internal bearing, spindle seals and thrust washer
  • 6 Bolt Holes
• Fits Jeep Wagoneer with Disc Brakes DANA 44 front axle

  • 1974, 1975, 1976
• Fits Jeep Cherokee with Disc Brakes DANA 44 front axle

  • 1974, 1975, 1976

DIMENSIONS:

• KEYWAY SLOT = .250 in. wide (1/4 inch)
• BORE ID = 1.300 inches
• A = 1.622 in. OD for Outer Wheel Bearing
• B = 1.778 in. OD for Inner Wheel Bearing
• C = 2-1/2 in. OD for Seal
• D = 3-3/8 in.
• E = 7/16 in.
• F = 3/8 in.
• G = 5-5/8 in.
• H = 6-1/2 in.
• K = 4-3/4 in.
• Bolt Holes = 6
• Bolt Hole Diameter = .400 in.

INCLUDES

• (1) Internal bearing factory installed
• (2) Rubber seals
• (1) Thrustwasher
