Dana Spicer 4-53-101 MIDSHIP SPLINE Fits 4.0 inch .083 wall tube 1.750 inch Diameter with 16 Splines
Part #:
4-53-101
Your Cost $160.83
Sorry, sold out

DANA SPICER 4-53-101

  • MIDSHIP SPLINE
  • Use with Center Support Bearing


Spicer
Dana Spicer 4-53-101 MIDSHIP SPLINE Fits 4.0 inch .083 wall tube 1.750 inch Diameter with 16 Splines
Dana Spicer 4-53-101 MIDSHIP SPLINE Fits 4.0 inch .083 wall tubing 1.750 inch Diameter with 16 Splines
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY BACK ORDER at this time
YOUR COST:  $160.83

>>>>> SPECIAL ORDER PART:  This part number is special ordered from the factory and shipped direct to you.  It is NOT Cancellable and NOT Returnable.  Please make your selection carefully! <<<<<

DANA SPICER 4-53-101

  • MIDSHIP SPLINE
  • Use with Center Support Bearing
  • Fits any series 16 Spline SLIP YOKE designed for 1.750 inch diameter spline
    • Fits TUBE DIAMETER = 4.0 inch OUTSIDE TUBE Diameter
    • Fits TUBE WALL THICKNESS =  .083 inch Tube wall thickness
    • Major SPLINE Diameter = 1.750
    • SPLINES = 16
    • STYLE = 1
    • B = 2.188
    • C = 1.772
    • G = .812
    • K = 8.562
    • L = 5.938
    • Y = 7.469
  • SPECIAL NOTES:
    • Blue GLIDECOAT on Spline for smooth operation and long life (DO NOT REMOVE this coating)



CLICK HERE : For ALL DANA SPICER Spline Part Numbers, Specifications and Dimensions

Dana Spicer 4-53-101 MIDSHIP SPLINE Fits 4.0 inch .083 wall tube 1.750 inch Diameter with 16 Splines

Dana Spicer 4-53-101 MIDSHIP SPLINE Fits 4.0 inch .083 wall tubing 1.750 inch Diameter with 16 Splines
