Dana Spicer 3-53-2011 MIDSHIP SPLINE Fits 3.5 inch .065 wall tube 1.500 inch Diameter with 15/16 Splines
Part Number:
3-53-2011


UPC:
023913231835
Your Cost $297.46 Sale Price $250.59
You Save $46.87
STATUS:  FACTORY DIRECT with FREE SHIPPING

DANA SPICER 3-53-2011

  • MIDSHIP SPLINE
  • Use with Center Support Bearing


Spicer
Dana Spicer 3-53-2011 MIDSHIP SPLINE Fits 3.5 inch .065 wall tube 1.500 inch Diameter with 15/16 Splines
Dana Spicer 3-53-2011 MIDSHIP SPLINE Fits 3.5 inch .065 wall tubing 1.500 inch Diameter with 15/16 Splines
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY DIRECT with FREE SHIPPING
YOUR COST:  $297.46 Sale Price $250.59
You Save $46.87

DANA SPICER 3-53-2011

  • MIDSHIP SPLINE
  • Use with Center Support Bearing
  • Fits any series 15 based on 16 Spline SLIP YOKE designed for 1.500 inch diameter spline
    • Fits TUBE DIAMETER = 3.5 inch OUTSIDE TUBE Diameter
    • Fits TUBE WALL THICKNESS =  .065 inch Tube wall thickness
    • Major SPLINE Diameter = 1.500
    • SPLINES = 15/16
    • STYLE = 2
    • B = 1.810
    • C = 1.575
    • G = .875
    • K = 9.350
    • L = 3.000
    • Y = 8.230
  • SPECIAL NOTES:
    • Blue GLIDECOAT on Spline for smooth operation and long life (DO NOT REMOVE this coating)



CLICK HERE : For ALL DANA SPICER Spline Part Numbers, Specifications and Dimensions

Dana Spicer 3-53-2011 MIDSHIP SPLINE Fits 3.5 inch .065 wall tube 1.500 inch Diameter with 15/16 Splines

Dana Spicer 3-53-2011 MIDSHIP SPLINE Fits 3.5 inch .065 wall tubing 1.500 inch Diameter with 15/16 Splines
