Dana Spicer 2-53-471 MIDSHIP SPLINE Fits 2.5 inch .083 wall tube 1.375 inch Diameter with 16 Splines
Part #:
2-53-471
Your Cost $85.98

DANA SPICER 2-53-471

  • MIDSHIP SPLINE
  • Use with Center Support Bearing


Spicer
Dana Spicer 2-53-471 MIDSHIP SPLINE Fits 2.5 inch .083 wall tube 1.375 inch Diameter with 16 Splines
Dana Spicer 2-53-471 MIDSHIP SPLINE Fits 2.5 inch .083 wall tubing 1.375 inch Diameter with 16 Splines
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY DIRECT TO YOU
YOUR COST:  $85.98

DANA SPICER 2-53-471

  • MIDSHIP SPLINE
  • Use with Center Support Bearing
  • Fits any series 16 Spline SLIP YOKE designed for 1.375 inch diameter spline
    • Fits TUBE DIAMETER = 2.5 inch OUTSIDE TUBE Diameter
    • Fits TUBE WALL THICKNESS =  .083 inch Tube wall thickness
    • Major SPLINE Diameter = 1.375
    • SPLINES = 16
    • STYLE = 1
    • B = 1.688
    • C = 1.378
    • G = .812
    • K = 8.000
    • L = 5.406
    • Y = 6.938
  • SPECIAL NOTES:
    • Blue GLIDECOAT on Spline for smooth operation and long life (DO NOT REMOVE this coating)



CLICK HERE : For ALL DANA SPICER Spline Part Numbers, Specifications and Dimensions

Dana Spicer 2-53-471 MIDSHIP SPLINE Fits 2.5 inch .083 wall tube 1.375 inch Diameter with 16 Splines

Dana Spicer 2-53-471 MIDSHIP SPLINE Fits 2.5 inch .083 wall tubing 1.375 inch Diameter with 16 Splines

You May Also Need These Parts to Complete the Job

DANA SPICER 211175X CENTER SUPPORT BEARING with 1.378 ID fits 2WD and 4WD FORD F100, F150, F250, F350 from 1948 to 2003 with 1-3/8 inch diameter spline
$28.20
