Dana Spicer 8-40-101 SPLINE Fits 4.5 inch .259 wall tube 3.0 inch Diameter with 16 Splines
Part #:
8-40-101
Your Cost $215.77

DANA SPICER 8-40-101

Spicer
Dana Spicer 8-40-101 SPLINE Fits 4.5 inch .259 wall tube 3.0 inch Diameter with 16 Splines
Dana Spicer 8-40-101 SPLINE Fits 4.5 inch .259 wall tubing 3.0 inch Diameter with 16 Splines
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $215.77

>>>>> SPECIAL ORDER PART:  This part number is special ordered from the factory and shipped direct to you.  It is NOT Cancellable and NOT Returnable.  Please make your selection carefully! <<<<<

DANA SPICER SPLINE 8-40-101

  • Fits any series 16 Spline SLIP YOKE designed for 3.0 inch diameter spline
  • Fits TUBE DIAMETER = 4.5 inch OUTSIDE TUBE Diameter
  • Fits TUBE WALL THICKNESS =  .259 inch Tube wall thickness
  • Major SPLINE Diameter = 3.000
  • SPLINES = 16
  • K = 11.531
  • L = 4.500
  • R = 10.219



CLICK HERE : For ALL DANA SPICER Spline Part Numbers, Specifications and Dimensions

image/jpeg
Dana Spicer 8-40-101 SPLINE Fits 4.5 inch .259 wall tube 3.0 inch Diameter with 16 Splines

Dana Spicer 8-40-101 SPLINE Fits 4.5 inch .259 wall tubing 3.0 inch Diameter with 16 Splines
