DANA SPICER 6.3-28-17 Weld Yoke 1760 Series fits 4.095 inch .180 wall tube

DANA SPICER 6.3-28-17

1760 Series Weld Yoke

• Fits 4.095 inch OD X .180 wall tubing
  • F - Butt Diameter = 3.743
• Series = 1760
• Lock up style = BEARING PLATE
• E - Universal Joint Width = 7.000
• D - Universal Joint Bore = 1.938
• H - Center of u-joint bore to point of weld = 3.031
• Special Notes: USE KIT 5-407X, 5-677X
