DANA SPICER 6-28-467 Weld Yoke 1710 Series fits 4.0 inch .134 wall tube

DANA SPICER 6-28-467

1710 Series Weld Yoke

• Fits 4.0 inch OD X .134 wall tubing
  • F - Butt Diameter = 3.743
• Series = 1710
• Lock up style = BEARING PLATE
• E - Universal Joint Width = 6.094

• D - Universal Joint Bore = 1.938

• H - Center of u-joint bore to point of weld = 3.688
• Special Notes: USE KIT 5-280X, 5-675X
• HIGH ANGLE YOKE

CLICK HERE : For ALL DANA SPICER Weld Yoke Part Numbers, Specifications and Dimensions
