DANA SPICER 6-28-137 Weld Yoke 1710 Series fits 3.5 inch .156 wall tube

DANA SPICER 6-28-137

1710 Series Weld Yoke

• Fits 3.5 inch OD X .156 wall tubing
  • F - Butt Diameter = 3.198
• Series = 1710
• Lock up style = BEARING PLATE
• E - Universal Joint Width = 6.094

• D - Universal Joint Bore = 1.938

• H - Center of u-joint bore to point of weld = 3.031
• Special Notes: USE KIT 5-280X, 5-675X
