DANA SPICER 5-28-887 Weld Yoke 1610 Series fits 3.5 inch .134 wall tube

DANA SPICER 5-28-887

1610 Series Weld Yoke

• Fits 3.5 inch OD X .134 wall tubing
  • F - Butt Diameter = 3.243
• Series = 1610
• Lock up style = BEARING PLATE
• E - Universal Joint Width = 5.312

• D - Universal Joint Bore = 1.875

• H - Center of u-joint bore to point of weld = 3.810
• Special Notes: USE KIT 5-279X, 5-674X
• HIGH ANGLE YOKE
