DANA SPICER 4-28-417 Weld Yoke 1550 Series fits 3.5 inch .095 wall tube

DANA SPICER 4-28-417

1550 Series Weld Yoke

• Fits 3.5 inch OD X .095 wall tubing
  • F - Butt Diameter = 3.321
• Series = 1550
• Lock up style = OUTSIDE SNAP RING
• E - Universal Joint Width = 4.964

• D - Universal Joint Bore = 1.375

• H - Center of u-joint bore to point of weld = 2.688
• Special Notes: USE KIT 5-155X, SPL70X
