Driveshaft and Driveline Parts > SPLINES for use with SLIP YOKE > Use with 4.000 x .083 TUBING > 1.562 - 16 splines

Dana Spicer 3-40-1551 SPLINE 8.940 inches Fits 4 inch .083 wall Driveshaft tube 1.562 inch Diameter with 16 Splines

Part Number:
3-40-1551

UPC:

023913219932

Your Cost ~~$136.51~~ Sale Price $115.00

You Save $21.51

STATUS: FACTORY DIRECT TO YOU

DANA SPICER 3-40-1551 SPLINE

Fits 4 inch .083 wall Driveshaft tubing

1.562 inch Diameter with 16 Splines

Spicer

Dana Spicer 3-40-1551 SPLINE 8.940 inches Fits 4 inch .083 wall Driveshaft tube 1.562 inch Diameter with 16 Splines

Dana Spicer 3-40-1551 SPLINE 8.940 inches Fits 4 inch .083 wall Driveshaft tube 1.562 inch Diameter with 16 Splines

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: FACTORY DIRECT TO YOU

YOUR COST: ~~$136.51~~ Sale Price $115.00

You Save $21.51

DANA SPICER SPLINE 3-40-1551

Fits any series 16 Spline SLIP YOKE designed for 1.562 inch diameter spline
Fits TUBE DIAMETER = 4 inch OUTSIDE TUBE Diameter
Fits TUBE WALL THICKNESS = .083 inch Tube wall thickness
Major SPLINE Diameter = 1.562
SPLINES = 16
K = 8.940
L = 3.0
R = 7.810

NOTE: This spline is typically used for 1410 and 1480 series driveshafts.

SCROLL DOWN to see the recommended parts to go with this spline part number.
Great for vehicles that require a larger tube diameter to handle the extra load of carrying heavy cargo or pulling trailers.
Great choice when a 4 inch tube is required for long length driveshafts.

image/jpeg

Dana Spicer 3-40-1551 SPLINE 8.940 inches Fits 4 inch .083 wall Driveshaft tube 1.562 inch Diameter with 16 Splines

Dana Spicer 3-40-1551 SPLINE 8.940 inches Fits 4 inch .083 wall Driveshaft tube 1.562 inch Diameter with 16 Splines

You May Also Need These Parts to Complete the Job

Dana Spicer 5-160X Universal Joint 1410 Series Part#: 5-160X $24.91	DANA SPICER 3-28-457 Weld Yoke 1410 Series to fit 4 inch .083 wall tube Part#: 3-28-457 $42.95
DANA SPICER 3-28-507 Weld Yoke 1480 Series to fit 4 inch .083 wall tube Part#: 3-28-507 ~~$58.13~~ $48.68	Dana Spicer 3-3-508KX Slip Yoke 1410 series 1.500 x 16 spline 7.812 inches Part#: 3-3-508KX $81.95
Dana Spicer 5-188X UNIVERSAL JOINT 1480 series Greaseable U-joint Part#: 5-188X $29.25	Dana Spicer SPL55X Universal Joint 1480 series NON Greaseable u-joint Part#: SPL55X $40.94
Dana Spicer 5-1410X Universal Joint 1410 Series NON Greaseable Part#: 5-1410X $31.70
