Dana Spicer 45531 Inner Axle Shaft 15 Spline at Disconnect 30 Spline at Diff Passenger Side 1994 to 1999 DODGE Ram 2500, 3500 with Dana 60 Disconnect
Diagram Number: 65
45531
Dana Spicer 45531
15 spline Inner Axle Shaft - Passenger Side
DODGE Ram 2500, 3500 with Dana 60 Disconnect front axle
- Fits 1994, 1995, 1996, 1997, 1998, 1999
- Connects the Disconnect Coupler to Differential Side Gear
- A = 19.77 inches
- B = 1.59 inches diameter
- 15 Splines at Disconnect Coupler
- C = 0.93 inches spline length
- D = 1.31 inches diameter
- 30 Splines at Differential Side Gear
- E = 2.0 inches spline length
- Passenger Side
Not Available
Pricing:
$214.23
Description
Dana Spicer 45531
15 spline Inner Axle Shaft - Passenger Side
DODGE Ram 2500, 3500 with Dana 60 Disconnect front axle
- Fits 1994, 1995, 1996, 1997, 1998, 1999
- Connects the Disconnect Coupler to Differential Side Gear
- A = 19.77 inches
- B = 1.59 inches diameter
- 15 Splines at Disconnect Coupler
- C = 0.93 inches spline length
- D = 1.31 inches diameter
- 30 Splines at Differential Side Gear
- E = 2.0 inches spline length
- Passenger Side
Details
- 45531
- 45531
- 023913134464
- Spicer
- Temporarily Not Available
- New
Shipping Information
- Item Requires Shipping
- 9.0 lbs.
- W4.0000” x H4.0000” x L20.0000”
- FREE SHIPPING ON PARTS ORDERS OVER $99
