DANA SPICER 10-2-29 Flange Yoke 1000 Series
Part #:
10-2-29
Your Cost $41.60

DANA SPICER 10-2-29

1000 Series Flange Yoke




Spicer
DANA SPICER 10-2-29 Flange Yoke 1000 Series
Dana Spicer 10-2-29 Flange Yoke
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $41.60

DANA SPICER 10-2-29

1000Series Flange Yoke

  • A - Flange or Swing Diameter = 3.375 inches
  • B - Bolt Circle Diameter = 2.750 inches
    • Bolt Hole Diameter = 0.312 inches
    • Bolt Holes = 4
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 2.250 inches
    • Center Pilot = MALE
  • Series = 1000
    • Inside "C" Clip Style
    • Width between inside lock surfaces = 1.5 inches
    • D - U-Joint Bearing cap diameter = .938 inches
  • G - Center of u-joint bore to Face of flange = 1.562 inches
  • X - inches
  • Y - inches
  • Special Notes: Use on 1000 series PTO applications





Denny's Driveshafts Flange Yoke Dimension Diagram

DANA SPICER 10-2-29 Flange Yoke 1000 Series

Dana Spicer 10-2-29 Flange Yoke

You May Also Need These Parts to Complete the Job

NEAPCO 1-0170 - PTO Universal Joint 1000 Series for Power Take Off
$13.60
DANA SPICER 5-170X - PTO Universal Joint 1000 Series for Power Take Off
$14.95
