DANA SPICER 3-3-6061X Slip Yoke 1.564 -23 based on 24 spline 1480 Series

DANA SPICER 3-3-6061X

1480 Series Slip Yoke

• Spline/Hole Outside Diameter = 1.564
• Number of Splines = 23/24
• Series = 1480
• Lock up style = OUTSIDE
• Universal Joint Width = 4.187
• D - Universal Joint Bore = 1.375
• Boot Kit Part Number for this yoke = 212007X ORDER BOOT SEPARATELY
• F - Center of u-joint bore to plug = 1.312
• J - Center of u-joint bore to End of Slip yoke = 6.810
• Special Notes:  ORDER BOOT SEPARATELY
