DANA SPICER 3-3-4871X Slip Yoke 1410 Series

DANA SPICER 3-3-4871X

1410 Series Slip Yoke

• Spline/Hole Outside Diameter = 1.500
• Number of Splines = 14/16
• Series = 1410
• Lock up style = OUTSIDE
• D - Universal Joint Bore = 1.187
• Boot Kit Part Number for this yoke = 212010X ORDER SEPARATELY
• F - Center of u-joint bore to plug = 1.156
• J - Center of u-joint bore to End of Slip yoke = 7.281
• Special Notes:  212010X ORDER SEPARATELY
