DANA SPICER 2-3-06028X Slip Yoke 1330 Series 1.375 14 based on 16 splines - this yoke has 2 wide splines

DANA SPICER 2-3-06028X

1330 Series Slip Yoke

• Spline/Hole Outside Diameter = 1.375
• Number of Splines = 14 based on 16 ...has 2 wide splines
• Series = 1330
• Lock up style = OUTSIDE
• Universal Joint Width = 3.625
• D - Universal Joint Bore = 1.062
• Boot Kit Part Number for this yoke = 211932X
• F - Center of u-joint bore to plug = 1.417
• J - Center of u-joint bore to End of Slip yoke = 7.039
