DANA SPICER 90-2-69-1 Flange Yoke SPL90 Series
90-2-69-1
DANA SPICER 90-2-69-1
SPL90 Series Flange Yoke
Shipping: >>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
Pricing:
$249.95
Description
DANA SPICER 90-2-69-1
SPL90 Series Flange Yoke
- A - Flange or Swing Diameter = 8 inches
- B - Bolt Circle Diameter = 7.250 inches
- Bolt Hole Diameter = 0.375 inches
- Bolt Holes = 8
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 7.750 inches
- Center Pilot = MALE
- Series = SPL90
- Outside Snap Ring Style
- U-Joint Width between snap rings = 4.957 inches
- D - U-Joint Bearing cap diameter = 1.625 inches
- G - Center of u-joint bore to Face of flange = 2.750 inches
- Special Notes: Bearing strap/half round style
Details
- 90-2-69-1
- 90-2-69-1
- Spicer
- Available
- New
Shipping Information
- Item Requires Shipping
- 13.0 lbs.
- W8.0000” x H4.0000” x L8.0000”
