DANA SPICER 6-2-1349 Flange Yoke 1710 Series
6-2-1349
DANA SPICER 6-2-1349
1710 Series Flange Yoke
Shipping: >>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
Pricing:
$319.63
Description
DANA SPICER 6-2-1349
1710 Series Flange Yoke
- A - Flange or Swing Diameter = 8 inches
- Bolt Circle Diameter = 7.250 inches
- Bolt Hole Diameter = 0.438 inches
- Bolt Holes = 8
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 7.750 inches
- Center Pilot = MALE
- Series = 1710
- U-Joint Width = 6.094 inches
- D - U-Joint Bearing cap diameter = 1.938 inches
- G - Center of u-joint bore to Face of flange = 2.500 inches
- Special Notes: Bearing Plate Style ...part has opening cast thru web
Details
- 6-2-1349
- 6-2-1349
- Spicer
- Available
- New
Shipping Information
- Item Requires Shipping
- 11.0 lbs.
- W8.0000” x H8.0000” x L4.0000”
- FREE SHIPPING ON PARTS ORDERS OVER $99
- >>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
