DANA SPICER 3-2-909 Flange Yoke 1480 Series
3-2-909
DANA SPICER 3-2-909
1480 Series Flange Yoke
Not Available
Pricing:
$155.95
Description
DANA SPICER 3-2-909
1480 Series Flange Yoke
- A - Flange or Swing Diameter = 6.875 inches
- B - Bolt Circle Diameter = 6.125 inches
- Bolt Hole Diameter = 0.386 inches
- Bolt Holes = 8
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 5.312 inches
- Center Pilot = MALE
- Series = 1480
- Outside Snap Ring Style
- U-Joint Width between snap rings = 4.187 inches
- D - U-Joint Bearing cap diameter = 1.375 inches
- G - Center of u-joint bore to Face of flange = 1.938 inches
- X - inches
- Y - inches
- Special Notes: FLANGE HAS PILOT FOR BRAKE
Details
- 3-2-909
- 3-2-909
- Spicer
- Temporarily Not Available
- New
Shipping Information
- Item Requires Shipping
- 6.0 lbs.
- W7.0000” x H7.0000” x L3.0000”
- FREE SHIPPING ON PARTS ORDERS OVER $99
