DANA SPICER 3-2-489 Flange Yoke 1480 Series
3-2-489
DANA SPICER 3-2-489
- 1480 Series Flange Yoke
Limited Supply: only 3 remaining
Pricing:
$80.58
Description
DANA SPICER 3-2-489
- 1480 Series Flange Yoke
Dimensions
- A - Flange or Swing Diameter = 5.875 inches
- B - Bolt Circle Diameter = 4.750 inches
- Bolt Hole Diameter = 0.500 inches
- Bolt Holes = 4
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 3.750 inches
- Center Pilot = MALE
- Series = 1480
- Outside Snap Ring Style
- U-Joint Width between snap rings = 4.187 inches
- D - U-Joint Bearing cap diameter = 1.375 inches
- G - Center of u-joint bore to Face of flange = 1.500 inches
- X - inches = 3.053
- Y - inches = 3.639
- Special Notes:
Details
- 3-2-489
- 3-2-489
- Spicer
- Available
- New
Shipping Information
- Item Requires Shipping
- 5.0 lbs.
- W6.0000” x H6.0000” x L2.0000”
