DANA SPICER 3-2-479 Flange Yoke 1480 Series
Part #:
3-2-479
Your Cost $39.98

DANA SPICER 3-2-479

1480 Series Flange Yoke




Spicer
DANA SPICER 3-2-479 Flange Yoke 1480 Series
DANA SPICER 3-2-479 Flange Yoke 1480 Series
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $39.98

DANA SPICER 3-2-479

1480 Series Flange Yoke

  • A - Flange or Swing Diameter = 5.750 inches
  • B - Bolt Circle Diameter = 4.750 inches
    • Bolt Hole Diameter = 0.500 inches
    • Bolt Holes = 4
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 3.750 inches
    • Center Pilot = MALE
  • Series = 1480
    • Outside Snap Ring Style
    • U-Joint Width between snap rings = 4.187 inches
    • D - U-Joint Bearing cap diameter = 1.375 inches
  • G - Center of u-joint bore to Face of flange = 2 inches
  • X - 3.053 inches
  • Y - 3.639 inches
  • Special Notes:





Denny's Driveshafts Flange Yoke Dimension Diagram

DANA SPICER 3-2-479 Flange Yoke 1480 Series

DANA SPICER 3-2-479 Flange Yoke 1480 Series
