DANA SPICER 2-2-1209 Flange Yoke 1330 Series
Part Number:
2-2-1209


UPC:
023913236113
Your Cost $104.63 Sale Price $88.14
You Save $16.49
STATUS:  FACTORY DIRECT TO YOU

DANA SPICER 2-2-1209

1330 Series Flange Yoke




Spicer
DANA SPICER 2-2-1209 Flange Yoke 1330 Series
DANA SPICER 2-2-1209 Flange Yoke 1330 Series
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY DIRECT TO YOU
YOUR COST:  $104.63 Sale Price $88.14
You Save $16.49

DANA SPICER 2-2-1209

1330Series Flange Yoke

  • A - Flange or Swing Diameter = 4.625 inches
  • B - Bolt Circle Diameter = 3.750 inches
    • Bolt Hole Diameter = 0.438 inches
    • Bolt Holes = 4
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 2.750 inches
    • Center Pilot = MALE
  • Series = 1330
    • Outside Snap Ring Style
    • U-Joint Width between snap rings = 3.625 inches
    • D - U-Joint Bearing cap diameter = 1.062 inches
  • G - Center of u-joint bore to Face of flange = 1.562 inches
  • X - inches
  • Y - inches
  • Special Notes:





Denny's Driveshafts Flange Yoke Dimension Diagram

DANA SPICER 2-2-1209 Flange Yoke 1330 Series

DANA SPICER 2-2-1209 Flange Yoke 1330 Series
