DANA SPICER 170-2-39-1 Flange Yoke SPL170 Series
Part Number:
170-2-39-1


UPC:
023913248567
Your Cost $430.72
Sorry, sold out
STATUS:  FACTORY BACK ORDER at this time

DANA SPICER 170-2-39-1

SPL170 Series Flange Yoke




Spicer
DANA SPICER 170-2-39-1 Flange Yoke SPL170 Series
GENERIC PHOTO
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY BACK ORDER at this time
YOUR COST:  $430.72

>>>>> SPECIAL ORDER PART:  This part number is special ordered from the factory and shipped direct to you.  It is NOT Cancellable and NOT Returnable.  Please make your selection carefully! <<<<<

DANA SPICER 170-2-39-1

SPL170 Series Flange Yoke

  • A - Flange or Swing Diameter = 8 inches
  • B - Bolt Circle Diameter = 7.250 inches
    • Bolt Hole Diameter = 0.479 inches
    • Bolt Holes = 12
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 7.750 inches
    • Center Pilot = MALE
  • Series = SPL170
    • U-Joint Width = 6.026 inches
    • D - U-Joint Bearing cap diameter = 2.166 inches
  • G - Center of u-joint bore to Face of flange = 3.375 inches
  • Special Notes: 12.2mm bolt holes on 1810 bolt pattern





Heavy duty truck and equipment driveshaft flange yokes at Denny's Driveshafts

DANA SPICER 170-2-39-1 Flange Yoke SPL170 Series

GENERIC PHOTO
