DANA SPICER 140-2-99-1 Flange Yoke SPL140 Series
140-2-99-1
DANA SPICER 140-2-99-1
SPL140 Series Flange Yoke
Shipping: >>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
Pricing:
$195.95
Description
DANA SPICER 140-2-99-1
SPL140 Series Flange Yoke
- A - Flange or Swing Diameter = 8 inches
- B - Bolt Circle Diameter = 7.250 inches
- Bolt Hole Diameter = 0.375 inches
- Bolt Holes = 8
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 7.750 inches
- Center Pilot = MALE
- Series = SPL140
- U-Joint Width = 5.028 inches
- D - U-Joint Bearing cap diameter = 1.937 inches
- G - Center of u-joint bore to Face of flange = 3.070 inches
- Special Notes: Mates with standard 1710 series companion flange
Details
- 140-2-99-1
- 140-2-99-1
- Spicer
- Available
- New
Shipping Information
- Item Requires Shipping
- 13.0 lbs.
- W8.0000” x H4.0000” x L8.0000”
