DANA SPICER 3-2-1659-1 Flange Yoke 1410 Series Strap and Bolt style
3-2-1659-1
DANA SPICER 3-2-1659-1
1410 Series Flange Yoke
Not Available
Pricing:
$204.95
Description
DANA SPICER 3-2-1659-1
1410Series Flange Yoke
- A - Flange or Swing Diameter = 6.750 inches
- B - Bolt Circle Diameter = 5.750 inches
- Bolt Hole Diameter = 0.484 inches
- Bolt Holes = 4
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 4.803 inches
- Center Pilot = FEMALE
- Series = 1410
- Outside Snap Ring Style
- U-Joint Width between snap rings = 4.187 inches
- D - U-Joint Bearing cap diameter = 1.187 inches
- G - Center of u-joint bore to Face of flange = 2 inches
- X - inches
- Y - inches
- Special Notes: Bearing strap style yoke w/brake pilot and bolt pattern
Details
- 3-2-1659-1
- 3-2-1659-1
- Spicer
- Temporarily Not Available
- New
Shipping Information
- Item Requires Shipping
- 9.0 lbs.
- W7.0000” x H7.0000” x L2.0000”
