Dana Spicer 212032-1X Center Support Bearing with .380 spacer plate 1.574 ID fits Chevy and GMC Suburban, Silverado, Sierra, Tahoe, Yukon
Part Number:
212032-1X


UPC:
023913230180
Your Cost $101.38 Sale Price $92.47
You Save $8.91
STATUS:  IN STOCK

DANA SPICER 212032-1X

Driveshaft Center Support Bearing with .380 inch spacer plate

  • NOTE: See 212028-1X for same bearing without spacer plate
  • Fits Chevy and GMC Suburban, Silverado, Sierra, Tahoe, Yukon
    • Scroll down for application information

Fits SPLINE OD = 1 1/2 inch

  • 212032-1X has (2) Metric Threaded Studs attached to bracket
  • 212032-1X has .380 inch SPACER PLATE attached to bracket
  • CENTER SUPPORT BEARING
    • RUBBER MOUNTED with canister,  with boot can included
  • A = ID of Bearing = 1.574 inches
  • B = CL to MOUNTING SURFACE = 2.630 inches
  • C = BRACKET WIDTH = 1.226 inches
  • D = MOUNTING HOLE Dimension = 6.620 inches
    • MOUNTING STUD Diameter =  M10 x 1.5 ... Metric Thread

REPLACES

  • GM 12472424
  • TIMKEN HB88515
  • NEAPCO N212032-1X







Spicer
Dana Spicer 212032-1X Center Support Bearing with .380 spacer plate 1.574 ID fits Chevy and GMC Suburban, Silverado, Sierra, Tahoe, Yukon
Dana Spicer 212032-1X Center Support Bearing with .380 spacer plate 1.574 ID fits Chevy and GMC Suburban, Silverado, Sierra, Tahoe, Yukon
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $101.38 Sale Price $92.47
You Save $8.91

DANA SPICER 212032-1X

Driveshaft Center Support Bearing with .380 inch spacer plate

  • NOTE: See 212028-1X for same bearing without spacer plate

Fits CHEVY and GMC

  • C1500 Suburban - 1999
  • K1500 - 1999
  • Silverado
    • 1500 - 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007
    • 1500HD - 2001, 2002, 2003 and 2005, 2006
    • 2500 - 2001, 2002, 2003, 2004
    • 3500 - 2001, 2002, 2003, 2004, 2005, 2006
  • Suburban 1500 - 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007
  • Suburban 2500 - 2001, 2002, 2003, 2004
  • Tahoe - 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007
  • Sierra
    • 1500 - 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007
    • 1500HD - 2001, 2002, 2003 and 2005, 2006
    • 2500 - 2001, 2002, 2003, 2004
    • 3500 - 2001, 2002, 2003, 2004, 2005, 2006
  • Yukon - 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007
  • Yukon 1500 XL - 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007
  • Yukon 2500 XL - 2001, 2002, 2003, 2004

DIMENSIONS

  • Fits SPLINE OD = 1-1/2 inches
  • 212032-1X has (2) Metric Threaded Studs attached to bracket
  • 212032-1X has .380 inch SPACER PLATE attached to bracket
  • CENTER SUPPORT BEARING
    • RUBBER MOUNTED with canister,  with boot can included
  • A = ID of Bearing = 1.574 inches
  • B = CL to MOUNTING SURFACE = 2.630 inches
  • C = BRACKET WIDTH = 1.226 inches
  • D = MOUNTING HOLE Dimension = 6.620 inches
    • MOUNTING STUD Diameter =  M10 x 1.5TH...Metric Thread

Dana Spicer 212032-1X center support bearing dimensions at Denny's Driveshafts



Dana Spicer 212032-1X Center Support Bearing with .380 spacer plate 1.574 ID fits Chevy and GMC Suburban, Silverado, Sierra, Tahoe, Yukon

Dana Spicer 212032-1X Center Support Bearing with .380 spacer plate 1.574 ID fits Chevy and GMC Suburban, Silverado, Sierra, Tahoe, Yukon

You May Also Need These Parts to Complete the Job

DANA SPICER 212094X Dust Boot for 2 piece driveshaft with center support bearing 2.185 ID x 2.323 ID x 7.500 inches long
$37.18 $33.14
