Dana Spicer 5003684 CENTER SUPPORT BEARING with 1.574 ID

SKU: 5003684

DANA SPICER 5003684

Center Support Bearing

Limited Supply: only 2 remaining

Pricing: $51.95

Description

DANA SPICER 5003684

Center Support Bearing

Fits 1.5 and also 1.562 inch DIAMETER SPLINE

5003684 has 1/2 inch spacer plate attached to bracket
- Please look at the photo carefully and you will see a 1/2 inch thick spacer factory welded to the mounting bracket
CENTER SUPPORT BEARING
- RUBBER MOUNTED with canister, without boot can
A = INSIDE DIAMETER of Bearing = 1.574 inches
B = CENTERLINE to MOUNTING SURFACE = 2.750 inches
C = BRACKET WIDTH = 1.226 inches
D = MOUNTING HOLE Dimension = 6.620 inches
- MOUNTING HOLE Diameter = .560 inch

PLEASE CLICK on Drawing Below for Larger View
