400083-411 Spline and Slip yoke set 1410 series fits 4.0 inch 0.083 wall steel tube allows maximum 3.000 inches of slip travel

400083-411

Spicer Spline and Slip yoke set

• Fits 4.0 inch steel tube OD with 0.083 wall thickness
• Fits 1410 series universal joint (see choices at bottom of page)
  • 4.188 wide cap to cap
  • 1.188 cap diameter
  • outside snap rings
• Maximum of 3.000 inches slip travel
• Spicer Slip yoke 1.500 x 16 splines, grease fitting in slip yoke barrel, has screw on seal
• Spicer Spline is glidecoated (blue coating) 3.00 inches for wear resistance if properly lubricated
  • Spline butt diameter to press fit into tube - 3.845 inches

The following dimensions are taken with the supplied seal installed.

• **CL to weld Collapsed Dimension - xxx inches
• **CL to weld Dimension at MID travel - xxx inches
• CL to weld Fully Extended Dimension - xxx inches

**Caution --- Using a rubber boot in place of the seal will lengthen the collapsed and mid point dimensions. You must factor this into your build dimensions before cutting, welding and building the driveshaft
