DT Components DRK-325AMK Master Bearing and Seal kit fits Chevy and GMC 10.5 inch 14 bolt full float rear LATE 1988 to 1997

Part Number: DRK325AMK

DRK-325AMK Master Differential Bearing and Seal Kit - DT Components

• DRK-325AMK Fits GM 10.5 inch 14 bolt REAR
  • Fits Chevy 3/4 ton Van and Pick Up Rear
    • LATE 1988 -1997 2nd Design
      • DOES NOT FIT..... 1988 with 1st design 10.5 inch rear end
      • See DRK-325MK for 1st Design
    • 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997
  • Fits Chevy 1 ton Van and Pick Up Rear
    • LATE 1988 -1997 2nd Design
      • DOES NOT FIT..... 1988 with 1st design 10.5 inch rear end
      • See DRK-325MK for 1st Design
    • 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997
  • Fits GMC 3/4 ton Van and Pick Up Rear
    • LATE 1988 -1997 2nd Design
      • DOES NOT FIT..... 1988 with 1st design 10.5 inch rear end
      • See DRK-325MK for 1st Design
    • 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997
  • Fits  GMC 1 ton Van and Pick Up Rear
    • LATE 1988 -1997 2nd Design
      • DOES NOT FIT..... 1988 with 1st design 10.5 inch rear end
      • See DRK-325MK for 1st Design
    • 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997

NOTE:

• NOTE: ALL LATE 1988 2nd Design will have large pinion head bearing numbers HM903249 - HM903210
• For SINGLE Rear Wheel vehicles use Wheel Bearing Kit number AK21
• Ring Gear BOLTS in this kit will fit up to 4.10 ratio.
  • If using 4.56 and higher ratio gears you will need RGB10 ring gear bolts

Parts included in DRK-325AMK

(2) Differential Bearing: 387AS - 382A
(1) Pinion Head Bearing: HM903249 - HM903210
(1) Pinion Tail Bearing: M802048 - M802011

(1) Pinion Nose Bearing: R1581TV

(1) Pinion Seal: 2286 (2.201 x 3.519)
(1) Crush Sleeve: CS325A
(1) Pinion Nut: PN7
(1) Gear Marking & Brush: GMC1-BR1
(1) Threadlocker: TL1
(1) Sealer RTV Silicone
(1) Pinion Depth Shims: SK14
(12) Ring Gear Bolts: RGB9
