DANA SPICER 250-2-10491 Serrated Flange Yoke SPL250 Series
250-2-10491
DANA SPICER 250-2-10491
SPL250 Series Serrated Flange Yoke
Shipping: >>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
Pricing:
$314.95
Description
DANA SPICER 250-2-10491
SPL250 Series Serrated Flange Yoke
- A - Flange or Swing Diameter = 0.000 inches
- B - Bolt Circle Diameter = 5.906 inches
- Bolt Hole Diameter = 0.591 inches
- Bolt Holes = 4
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter
- Center Pilot
- Series = SPL250
- U-Joint Width = 5.986 inches
- D - U-Joint Bearing cap diameter = 2.362 inches
- G - Center of u-joint bore to Face of flange = 3.583 inches
- Special Notes: 180 mm flange with serrated flange face
Details
- 250-2-10491
- 250-2-10491
- Spicer
- Available
- New
Shipping Information
- Item Requires Shipping
- 15.0 lbs.
- W8.0000” x H4.0000” x L8.0000”
