Dana Spicer 2-1-1313-9 PTO Companion Flange 1.625 inch Round Bore with 0.375 Keyway, 3.125 Bolt Circle, 2.375 female pilot

Dana Spicer 2-1-1313-9

COMPANION FLANGE for power take off applications

Series 1280, 1310

• P  - 1.625 Inch Diameter Bore
  • X - 0.375 in. Keyway

• C - 2.375 in Female Pilot
• B - Bolt Circle Diameter - 3.125 in
  • 4 Bolt Holes 0.375 in. Diameter Drilled
  • Bolt Pattern - Rectangular
    • 2.0 inches
    • 2.375 inches

• W - Set Screw THREAD Diameter  - 0.375 in.

  • W - Set Screw Location - 12
  • Set Screw Included

• R - Hub Diameter - 2.438 in.

• F - Length Through Hole -  1.900 in.

• G - Flange Face to End of Hub  - 2.000 in.

• A - Total Swing Diameter - 3.875 in.
