Driveshaft and Driveline Parts > PARTS - NEW ARRIVALS

Dana Spicer 3-4-13821-1 End Yoke 1.750-10 spline 1480 series strap and bolt style

Part Number:
3-4-13821-1

UPC:

023913216429

Your Cost $95.14

STATUS: FACTORY DIRECT TO YOU

Dana Spicer 3-4-13821-1

END YOKE - 10 SPLINES
Fits SPLINED SHAFT 1.750
1480 series
Strap and Bolt style
- Strap and bolt set can be purchased separately at the bottom of this page.

DIMENSIONS

SPLINE OD = 1.750
D = 1.375
E = 4.188
Q = 2.120
R = 2.362
S = 4.215

Genuine Dana Spicer End Yoke

Spicer

Dana Spicer 3-4-13821-1 End Yoke 1.750-10 spline 1480 series strap and bolt style

Dana Spicer 3-4-13821-1 End Yoke 1.750-10 spline 1480 series strap and bolt style

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: FACTORY DIRECT TO YOU

YOUR COST: $95.14

Dana Spicer 3-4-13821-1

END YOKE - 10 SPLINES
Fits SPLINED SHAFT 1.750
1480 series
Strap and Bolt style
- Strap and bolt set can be purchased separately at the bottom of this page.

DIMENSIONS

SPLINE OD = 1.750
D = 1.375
E = 4.188
Q = 2.120
R = 2.362
S = 4.215

Genuine Dana Spicer End Yoke

image/jpeg

Dana Spicer 3-4-13821-1 End Yoke 1.750-10 spline 1480 series strap and bolt style

Dana Spicer 3-4-13821-1 End Yoke 1.750-10 spline 1480 series strap and bolt style

You May Also Need These Parts to Complete the Job

Dana Spicer 5-188X UNIVERSAL JOINT 1480 series Greaseable U-joint Part#: 5-188X $29.25	Dana Spicer SPL55X Universal Joint 1480 series NON Greaseable u-joint Part#: SPL55X $40.94
DANA SPICER 3-70-38X Strap and Bolt set fits 1.375 bearing cap diameter 2.130 CL on 1480 and 1550 series end yokes, transmission, transfer case and differential yokes Part#: 3-70-38X $9.95
