Dana Spicer 4-2-1069 Flange Yoke 1550 Series
Part Number:
4-2-1069


UPC:
023913700577
Your Cost $92.48 Sale Price $77.91
You Save $14.57
Sorry, sold out
STATUS:  FACTORY BACK ORDER at this time

DANA SPICER 4-2-1149

1550 Series Flange Yoke

  • A - Flange or Swing Diameter = 5.906 inches
  • B - Bolt Circle Diameter = 5.125 inches
    • Bolt Hole Diameter = 0.484 inches
    • Bolt Holes = 8
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 3.547 inches
    • Center Pilot = MALE
  • Series = 1550
    • Outside Snap Ring Style
    • U-Joint Width between snap rings = 4.964 inches
    • D - U-Joint Bearing cap diameter = 1.375 inches
  • G - Center of u-joint bore to Face of flange = 3.156 inches
  • Design = Rectangular
  • Special Notes: Use with Dana Spicer 5-155X, 5-808X or 5-809X
Spicer
Dana Spicer 4-2-1069 Flange Yoke 1550 Series
DANA SPICER 4-2-1069 Flange Yoke 1550 Series
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY BACK ORDER at this time
YOUR COST:  $92.48 Sale Price $77.91
You Save $14.57

DANA SPICER 4-2-1149

1550 Series Flange Yoke

  • A - Flange or Swing Diameter = 5.906 inches
  • B - Bolt Circle Diameter = 5.125 inches
    • Bolt Hole Diameter = 0.484 inches
    • Bolt Holes = 8
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 3.547 inches
    • Center Pilot = MALE
  • Series = 1550
    • Outside Snap Ring Style
    • U-Joint Width between snap rings = 4.964 inches
    • D - U-Joint Bearing cap diameter = 1.375 inches
  • G - Center of u-joint bore to Face of flange = 3.156 inches
  • Design = Rectangular
  • Special Notes: Use with Dana Spicer 5-155X, 5-808X or 5-809X



Denny's Driveshafts Flange Yoke Dimension Diagram

Dana Spicer 4-2-1069 Flange Yoke 1550 Series

DANA SPICER 4-2-1069 Flange Yoke 1550 Series
